H-5168, H-5169
π
H-5170
POLE/WALL MOUNT
RECEPTACLE
TOOLS NEEDED
Tin Snips
Metal Strap x 2
(Inlcuded with H-5168 and H-5169)
PAGE 1 OF 2
1-800-295-5510
uline.com
Flat Head Screwdriver
Buckle x 4
(Included with H-5168
and H-5169)
Bolt x 4
(Included with H-5170)
1/2" Wrench
PARTS
Bolt x 2
(Included with H-5168
and H-5169)
Lock Washer x 4
(Included with H-5170)
Nut x 2
(Included with H-5168
and H-5169)
0715 IH-5168
