U-Line H-5443 Manual

H-5443
TILTING LIFT TABLE
1. Read all instructions carefully before operating the
lift table.
2. DO NOT overload the lift table and always operate
within the rated load. Overloading will cause
damage to the lift table and the operator.
3. DO NOT stand or sit on the table to work.
4. DO NOT put hands or feet under the table when
lowering.
5. Apply the brakes while loading to prevent the table
from moving.
6. DO NOT load loose or unstable loads onto the table.
7. DO NOT leave the table loaded for extended
periods of time.
PAGE 1 OF 12
1-800-295-5510
uline.com
TECHNICAL INFORMATION
SPECIFICATIONS
Capacity
Height Raised (Top)
Height Raised (Bottom)
Height Lowered
Actual Table Size
Usable Table Size
Handle Height
Retaining Lip Height
Overall Length
Foot Pedal Cycles to Max. Height
Wheel Diameter
Weight
GENERAL INFORMATION
Pour le français, consulter les pages 9-12.
H-5443
660 lbs.
50¼"
31½"
13½"
35½ x 23¾"
31¾ x 23¾"
38¾"
7"
45"
32
5"
189 lbs.
8. DO NOT move the truck while lifting.
9. The table should only be used on flat, solid surfaces.
10. Make sure not to overload the table when it is in
the raised position. The safety valve only works as
the table is lifted. Overloading in the raised position
may damage the table.
11. When loading and unloading goods in the raised
position, do not drag loads across the table.
This may cause offset loading and the table may
turn over.
12. When maintaining and repairing the table, the
stand bar should be used to support the fork arm in
order to prevent table from falling. There should not
be a load on table while maintaining and repairing
the table.
Para Español, vea páginas 5-8.
0821 IH-5443
