Proline 100 Modbus RS485
6.2
Structure and function of the operating menu
6.2.1
Structure of the operating menu
11
Schematic structure of the operating menu
6.2.2
Operating philosophy
The individual parts of the operating menu are assigned to certain user roles (operator,
maintenance etc.). Each user role contains typical tasks within the device lifecycle.
For detailed information on the operating philosophy, see the Operating Instructions for
the device.
Endress+Hauser
Operating menu for operators and maintenances
Language
Operation
Setup
Diagnostics
Operating menu for experts
Expert
task-oriented
function-oriented
Operation options
A0014058-EN
25
