KA01405D/06/EN/01.18
71415024
2018-11-01
Products
Brief Operating Instructions
Proline 300
PROFIBUS PA
Transmitter with electromagnetic sensor
These instructions are Brief Operating Instructions; they are
not a substitute for the Operating Instructions pertaining to
the device.
Transmitter Brief Operating Instructions
Contain information about the transmitter.
Sensor Brief Operating Instructions →  3
Solutions
Services

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Proline 300 and is the answer not in the manual?

Questions and answers

Related Manuals for Endress+Hauser Proline 300

Summary of Contents for Endress+Hauser Proline 300

  • Page 1 Products Solutions Services KA01405D/06/EN/01.18 71415024 2018-11-01 Brief Operating Instructions Proline 300 PROFIBUS PA Transmitter with electromagnetic sensor These instructions are Brief Operating Instructions; they are not a substitute for the Operating Instructions pertaining to the device. Transmitter Brief Operating Instructions Contain information about the transmitter.
  • Page 2 Proline 300 PROFIBUS PA Order code: XXXXX-XXXXXX Ser. no.: XXXXXXXXXXXX Ext. ord. cd.: XXX.XXXX.XX Serial number www.endress.com/deviceviewer Endress+Hauser Operations App A0023555 Endress+Hauser...
  • Page 3 These Brief Operating Instructions are the Transmitter Brief Operating Instructions. The "Sensor Brief Operating Instructions" are available via: • Internet: www.endress.com/deviceviewer • Smart phone/tablet: Endress+Hauser Operations App Detailed information about the device can be found in the Operating Instructions and the other documentation: • Internet: www.endress.com/deviceviewer...

  • Page 4: Table Of Contents

    Table of contents Proline 300 PROFIBUS PA Table of contents About this document ............. . 5 Symbols used .

  • Page 5: About This Document

    Proline 300 PROFIBUS PA About this document About this document Symbols used 1.1.1 Safety symbols Symbol Meaning DANGER! DANGER This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in serious or fatal injury. WARNING! This symbol alerts you to a dangerous situation.
  • Page 6 About this document Proline 300 PROFIBUS PA Symbol Meaning Protective Earth (PE) A terminal which must be connected to ground prior to establishing any other connections. The ground terminals are situated inside and outside the device: • Inner ground terminal: Connects the protectiv earth to the mains supply.

  • Page 7: Basic Safety Instructions

    Proline 300 PROFIBUS PA Basic safety instructions Basic safety instructions Requirements for the personnel The personnel must fulfill the following requirements for its tasks: ‣ Trained, qualified specialists must have a relevant qualification for this specific function and task. ‣...

  • Page 8: Workplace Safety

    Verification for borderline cases: ‣ For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance in verifying the corrosion resistance of fluid-wetted materials, but does not accept any warranty or liability as minute changes in the temperature, concentration or level of contamination in the process can alter the corrosion resistance properties.

  • Page 9: Security

    Proline 300 PROFIBUS PA Basic safety instructions IT security Our warranty is valid only if the device is installed and used as described in the Operating Instructions. The device is equipped with security mechanisms to protect it against any inadvertent changes to the settings.

  • Page 10: Product Description

    Product description Proline 300 PROFIBUS PA Product description The device consists of a Proline 300 transmitter and an electromagnetic Proline Promag sensor. The device is available as a compact version: The transmitter and sensor form a mechanical unit. N ic...

  • Page 11: Installation

    Proline 300 PROFIBUS PA Installation Installation For detailed information about mounting the sensor, see the Sensor Brief Operating Instructions →  3 Turning the transmitter housing To provide easier access to the connection compartment or display module, the transmitter housing can be turned.

  • Page 12: Turning The Display Module

    Installation Proline 300 PROFIBUS PA Turning the display module The display module can be turned to optimize display readability and operability. – – – 3 mm A0030035 Depending on the device version: Loosen the securing clamp of the connection compartment cover.

  • Page 13: Electrical Connection

    Proline 300 PROFIBUS PA Electrical connection Electrical connection NOTICE The measuring device does not have an internal circuit breaker. ‣ For this reason, assign the measuring device a switch or power-circuit breaker so that the power supply line can be easily disconnected from the mains.
  • Page 14 Electrical connection Proline 300 PROFIBUS PA Signal cable PROFIBUS PA Twisted, shielded two-wire cable. Cable type A is recommended . For further information on planning and installing PROFIBUS networks see: • Operating Instructions "PROFIBUS DP/PA: Guidelines for planning and commissioning"...
  • Page 15 Proline 300 PROFIBUS PA Electrical connection Standard cable - customer-specific cable No cable is supplied, and it must be provided by the customer (up to max. 300 m (1 000 ft)) for the following order option: Order code for DKX001: Order code 040 for "Cable", option 1 "None, provided by customer, max 300 m"...
  • Page 16 Electrical connection Proline 300 PROFIBUS PA 5.1.3 Terminal assignment Transmitter: supply voltage, input/outputs The terminal assignment of the inputs and outputs depends on the individual order version of the device. The device-specific terminal assignment is documented on an adhesive label in the terminal cover.

  • Page 17: Connecting The Measuring Device

    Proline 300 PROFIBUS PA Electrical connection Connecting the measuring device NOTICE Limitation of electrical safety due to incorrect connection! ‣ Have electrical connection work carried out by appropriately trained specialists only. ‣ Observe applicable federal/national installation codes and regulations. ‣...
  • Page 18 Electrical connection Proline 300 PROFIBUS PA N ic N ic t e r t e r e r g ö f f e r g ö f f iz e iz e t e n t e n r ir...
  • Page 19 Proline 300 PROFIBUS PA Electrical connection 22 mm 24 mm – A0029816 10. Connect the cable in accordance with the terminal assignment .  Signal cable terminal assignment: The device-specific terminal assignment is documented on an adhesive label in the terminal cover.

  • Page 20: Ensuring Potential Equalization

    Electrical connection Proline 300 PROFIBUS PA 5.2.2 Connecting the remote display and operating module DKX001 The remote display and operating module DKX001 is available as an optional extra. • The measuring device is always supplied with a dummy cover when the remote display and operating module DKX001 is ordered directly with the measuring device.
  • Page 21 • Grounding rings can be ordered separately as an accessory from Endress+Hauser . When ordering make sure that the grounding rings are compatible with the material used for the...
  • Page 22 Electrical connection Proline 300 PROFIBUS PA Potential equalization via grounding electrodes on process connection A0028972 Hexagonal-headed bolts of process connection Integrated grounding electrodes O-ring seal Sensor 5.3.2 Promag P For devices intended for use in hazardous locations, please observe the guidelines in the Ex documentation (XA).
  • Page 23 Proline 300 PROFIBUS PA Electrical connection Plastic pipe or pipe with insulating liner This connection method also applies in situations where: • The customary potential equalization is not used • Equalizing currents are present Ground cable Copper wire, at least 6 mm (0.0093 in...
  • Page 24 Electrical connection Proline 300 PROFIBUS PA Connect the measuring device to the power supply such that it is floating in relation to the protective ground (isolation transformer). Endress+Hauser...

  • Page 25: Hardware Settings

    Proline 300 PROFIBUS PA Electrical connection Hardware settings 5.4.1 Setting the device address The address must always be configured for a PROFIBUS DP/PA device. The valid address range is between 1 and 126. In a PROFIBUS DP/PA network, each address can only be assigned once.

  • Page 26: Ensuring The Degree Of Protection

    Electrical connection Proline 300 PROFIBUS PA Software addressing ‣ To switch addressing from hardware addressing to software addressing: set DIP switch No. 4 to Off.  The device address configured in the Device address parameter takes effect after 10 seconds. The device is restarted.

  • Page 27: Post-Connection Check

    Proline 300 PROFIBUS PA Electrical connection To ensure that moisture does not enter the cable entry: Route the cable so that it loops down before the cable entry ("water trap").  A0029278 Insert dummy plugs into unused cable entries. Post-connection check Are cables or the device undamaged (visual inspection)? ...

  • Page 28: Operation Options

    Operation options Proline 300 PROFIBUS PA Operation options Overview of operation options A0034513 Local operation via display module Computer with Web browser (e.g. Internet Explorer) or with operating tool (e.g. FieldCare, DeviceCare, AMS Device Manager, SIMATIC PDM) Field Xpert SFX350 or SFX370...

  • Page 29: Structure And Function Of The Operating Menu

    Proline 300 PROFIBUS PA Operation options Structure and function of the operating menu 6.2.1 Structure of the operating menu Operating menu for operators and maintenances Language Operation task-oriented Setup Diagnostics Operating menu for experts Expert function-oriented A0014058-EN  2 Schematic structure of the operating menu 6.2.2...

  • Page 30: Access To The Operating Menu Via The Local Display

    Operation options Proline 300 PROFIBUS PA Access to the operating menu via the local display X X X X X X 19.184 mA 12.5 X X X X X X Language 20.50 Ã English Deutsch Español Français Xxxxxxx A B C D E F G H I J K M N O P Q R S T U V W +0.000 Xx...
  • Page 31 Proline 300 PROFIBUS PA Operation options 6.3.1 Operational display Explanatory symbols for the measured value Status area • Depends on the device version, e.g.: The following symbols appear in the status area of the – : Volume flow operational display at the top right: –...
  • Page 32 Operation options Proline 300 PROFIBUS PA Numeric editor Confirms selection. Moves the input position one position to the left. Exits the input without applying the changes. Inserts decimal separator at the input position. Inserts minus sign at the input position.

  • Page 33: Access To The Operating Menu Via The Operating Tool

    Proline 300 PROFIBUS PA System integration Keys and meaning Minus/Enter key combination (press the keys simultaneously) With an operational display: • If keypad lock is active: Press the key for 3 s: Deactivates the keypad lock. • If keypad lock is not active: Press the key for 3 s: Opens the context menu including the option for activating the keypad lock.

  • Page 34: Commissioning

    Commissioning Proline 300 PROFIBUS PA Commissioning Function check Before commissioning the measuring device: ‣ Make sure that the post-installation and post-connection checks have been performed. • "Post-installation check" checklist →  12 • "Post-connection check" checklist →  27 Setting the operating language...

  • Page 35: Configuring The Measuring Device

    Proline 300 PROFIBUS PA Commissioning Configuring the measuring device The Setup menu with its submenus and guided wizards is used for fast commissioning of the device. They contain all the parameters required for configuration, such as for measurement or communication.

  • Page 36: Diagnostic Information

    Diagnostic information Proline 300 PROFIBUS PA Diagnostic information Faults detected by the self-monitoring system of the measuring device are displayed as a diagnostic message in alternation with the operational display. The message about remedial measures can be called up from the diagnostic message, and contains important information on the fault.
