  • Page 1 Products Solutions Services KA01335D/06/EN/01.17 71377320 Brief Operating Instructions Proline 100 Modbus RS485 Transmitter with Coriolis sensor These instructions are Brief Operating Instructions; they are not a substitute for the Operating Instructions pertaining to the device. Transmitter Brief Operating Instructions Contain information about the transmitter. Sensor Brief Operating Instructions →...
  • Page 2 Proline 100 Modbus RS485 Order code: XXXXX-XXXXXX Ser. no.: XXXXXXXXXXXX Ext. ord. cd.: XXX.XXXX.XX Serial number www.endress.com/deviceviewer Endress+Hauser Operations App A0023555 Endress+Hauser...
  • Page 3 These Brief Operating Instructions are the Transmitter Brief Operating Instructions. The "Sensor Brief Operating Instructions" are available via: • Internet: www.endress.com/deviceviewer • Smart phone/tablet: Endress+Hauser Operations App Detailed information about the device can be found in the Operating Instructions and the other documentation: • Internet: www.endress.com/deviceviewer...
  • Page 4: Table Of Contents

    Table of contents Proline 100 Modbus RS485 Table of contents Document information ............5 Symbols used .
  • Page 5: Document Information

    Proline 100 Modbus RS485 Document information Document information Symbols used 1.1.1 Safety symbols Symbol Meaning DANGER! DANGER This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in serious or fatal injury. WARNING! This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in WARNING serious or fatal injury.
  • Page 6 Document information Proline 100 Modbus RS485 Symbol Meaning Protective Earth (PE) A terminal which must be connected to ground prior to establishing any other connections. The ground terminals are situated inside and outside the device: • Inner ground terminal: Connects the protectiv earth to the mains supply.
  • Page 7: Basic Safety Instructions

    Proline 100 Modbus RS485 Basic safety instructions Basic safety instructions Requirements for the personnel The personnel must fulfill the following requirements for its tasks: ‣ Trained, qualified specialists must have a relevant qualification for this specific function and task. ‣...
  • Page 8: Workplace Safety

    Verification for borderline cases: ‣ For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance in verifying the corrosion resistance of fluid-wetted materials, but does not accept any warranty or liability as minute changes in the temperature, concentration or level of contamination in the process can alter the corrosion resistance properties.
  • Page 9: It Security

    Proline 100 Modbus RS485 Product description IT security We only provide a warranty if the device is installed and used as described in the Operating Instructions. The device is equipped with security mechanisms to protect it against any inadvertent changes to the device settings.
  • Page 10 Installation Proline 100 Modbus RS485 Aluminum housing version 3 mm A0023192 Compact and ultra-compact housing versions 8 mm A0023195 Endress+Hauser...
  • Page 11: Electrical Connection

    Proline 100 Modbus RS485 Electrical connection Electrical connection NOTICE The measuring device does not have an internal circuit breaker. ‣ For this reason, assign the measuring device a switch or power-circuit breaker so that the power supply line can be easily disconnected from the mains.
  • Page 12 Electrical connection Proline 100 Modbus RS485 Connecting cable between Safety Barrier Promass 100 and measuring device Cable type Shielded twisted-pair cable with 2x2 wires. When grounding the cable shield, observe the grounding concept of the plant. Maximum cable resistance 2.5 Ω, one side Comply with the maximum cable resistance specifications to ensure the operational reliability of the measuring device.
  • Page 13 Proline 100 Modbus RS485 Electrical connection Device version with Modbus RS485 communication protocol A0019528  1 Modbus RS485 terminal assignment, connection version for use in non-hazardous areas and Zone 2/Div. 2 Power supply: DC 24 V Output: Modbus RS485 A0017053 ...
  • Page 14 Electrical connection Proline 100 Modbus RS485 Safety Barrier Promass 100 Power Modbus supply RS485 Safe area Power Lift panel for bus termination Communication Safety Barrier Promass 100 Hazardous area Power Modbus supply RS485 A0016922  3 Safety Barrier Promass 100 with terminals Non-hazardous area and Zone 2/Div.
  • Page 15 Proline 100 Modbus RS485 Electrical connection Assignment DC 24 V Not assigned Not assigned DC 24 V Grounding/shielding Coding Plug/socket Plug A0016809 Signal transmission Promass Device plug for signal transmission (device side), MODBUS RS485 (not intrinsically safe) For use in the non-hazardous area and Zone 2/Div. 2.
  • Page 16 Electrical connection Proline 100 Modbus RS485 NOTICE In systems without potential matching, the multiple grounding of the cable shield causes mains frequency equalizing currents! Damage to the bus cable shield. ‣ Only ground the bus cable shield to either the local ground or the protective ground at one end.
  • Page 17: Connecting The Measuring Device

    Proline 100 Modbus RS485 Electrical connection Connecting the measuring device NOTICE Limitation of electrical safety due to incorrect connection! ‣ Have electrical connection work carried out by appropriately trained specialists only. ‣ Observe applicable federal/national installation codes and regulations. ‣...
  • Page 18 Electrical connection Proline 100 Modbus RS485 8 mm 8 mm 3 mm 10 (0.4) mm (in) A0017844  5 Device versions with connection examples Cable Device plug for signal transmission Device plug for supply voltage ‣ Connect the cable in accordance with the terminal assignment →  12 or the device plug pin assignment .
  • Page 19 Proline 100 Modbus RS485 Electrical connection L- L+ A0028766  6 Electrical connection between the transmitter and Safety Barrier Promass 100 Control system (e.g. PLC) Observe cable specifications →  11 Safety Barrier Promass 100: terminal assignment Observe cable specifications →  11 Non-hazardous area Non-hazardous area and Zone 2/Div.
  • Page 20: Special Connection Instructions

    Electrical connection Proline 100 Modbus RS485 Special connection instructions 5.3.1 Connection examples Modbus RS485 Modbus RS485, non-hazardous area and Zone 2/Div. 2 A0028765  7 Connection example for Modbus RS485, non-hazardous area and Zone 2/Div. 2 Control system (e.g. PLC) Cable shield: the cable shield must be grounded at both ends to comply with EMC requirements;...
  • Page 21: Hardware Settings

    Proline 100 Modbus RS485 Electrical connection Modbus RS485 intrinsically safe L- L+ A0028766  8 Connection example for Modbus RS485 intrinsically safe Control system (e.g. PLC) Cable shield, observe cable specifications Safety Barrier Promass 100 Observe cable specifications Non-hazardous area Non-hazardous area and Zone 2/Div.
  • Page 22 Electrical connection Proline 100 Modbus RS485 If the transmitter is used in the non-hazardous area or Zone 2/Div. 2 4 - Bus termination 3 - Not used 220 W 2 - Not used 1 - Write protection A0017610  9...
  • Page 23: Ensuring The Degree Of Protection

    Proline 100 Modbus RS485 Electrical connection Ensuring the degree of protection The measuring device fulfills all the requirements for the IP66/67 degree of protection, Type 4X enclosure. To guarantee IP66/67 degree of protection, Type 4X enclosure, carry out the following steps after the electrical connection: Check that the housing seals are clean and fitted correctly.
  • Page 24: Operation Options

    Operation options Proline 100 Modbus RS485 Operation options Overview of operating options A0017760 Computer with "FieldCare" or "DeviceCare" operating tool via Commubox FXA291 and service interface Control system (e.g. PLC) Endress+Hauser...
  • Page 25: Structure And Function Of The Operating Menu

    Proline 100 Modbus RS485 Operation options Structure and function of the operating menu 6.2.1 Structure of the operating menu Operating menu for operators and maintenances Language Operation task-oriented Setup Diagnostics Operating menu for experts Expert function-oriented A0014058-EN  11 Schematic structure of the operating menu 6.2.2...
  • Page 26: Access To The Operating Menu Via The Operating Tool

    Operation options Proline 100 Modbus RS485 Access to the operating menu via the operating tool 6.3.1 Connecting the operating tool Via service interface (CDI) Modbus RS485 A0030216 Service interface (CDI) of measuring device Commubox FXA291 Computer with "FieldCare" operating tool with COM DTM "CDI Communication FXA291"...
  • Page 27 FieldCare Function scope FDT-based plant asset management tool from Endress+Hauser. It can configure all smart field devices in a system and helps you manage them. By using the status information, it is also a simple but effective way of checking their status and condition.
  • Page 28 Operation options Proline 100 Modbus RS485 Establishing a connection Start FieldCare and launch the project. In the network: Add a device.  The Add device window opens. Select the CDI Communication FXA291 option from the list and press OK to confirm.
  • Page 29 Proline 100 Modbus RS485 Operation options User interface Xxxxxx/…/…/ Device name: Xxxxxxx kg/h Mass flow: 12.34 Device tag: Xxxxxxx Volume flow: 12.34 m /h ³ Status: Good Xxxxxx Mass flow unit: kg/h Access status tooling Maintenance Volume flow unit: m /h ³...
  • Page 30: System Integration

    System integration Proline 100 Modbus RS485 System integration For detailed information on system integration, see the Operating Instructions for the device. • Overview of device description files – Current version data for the device – Operating tools • Compatibility with previous model •...
  • Page 31: Protecting Settings From Unauthorized Access

    Proline 100 Modbus RS485 Diagnostic information Protecting settings from unauthorized access The following write protection options exist in order to protect the configuration of the measuring device from unintentional modification: • Protect access to parameters via access code • Protect access to local operation via key locking •...
  • Page 32 Diagnostic information Proline 100 Modbus RS485 Xxxxxx/…/…/ Device name: Xxxxxxx Mass flow: kg/h 12.34 Device tag: Xxxxxxx Volume flow: 12.34 m /h ³ Status signal: Function check (C) Xxxxxx Diagnostics 1: C485 Simu... Remedy information: Deactivate... Failure (F) Access status tooling:...
  • Page 36 www.addresses.endress.com...
