System integration

7 System integration
For detailed information on system integration, see the Operating Instructions for the
device.
• Overview of device description files
– Current version data for the device
– Operating tools
• Compatibility with previous model
• Modbus RS485 information
– Function codes
– Response time
– Modbus data map
8

Commissioning

8.1

Function check

Before commissioning the measuring device:
‣
Make sure that the post-installation and post-connection checks have been performed.
• "Post-installation check" checklist
• "Post-connection check" checklist →  23
8.2

Setting the operating language

Factory setting: English or ordered local language
The operating language can be set in FieldCare or DeviceCare: Operation → Display language
8.3

Configuring the measuring device

The Setup menu with its submenus enable fast commissioning of the measuring device. The
submenus contain all the parameters required for configuration, such as parameters for
measurement or communication.
The submenus available in the particular device can vary on account of the device version
(e.g. sensor).
Submenu
Medium selection
Output conditioning
System units
Communication
Low flow cut off
Partially filled pipe detection
30
Meaning
Define the medium
Define the output conditioning
Configure the units for all measured values
Configure the digital communication interface
Set the low flow cut off
Configure partial and empty pipe detection
