Performer Cyc Q6
3 CH 8 CH 13 CH
(BASIC)
(SSP) (TOUR)
13
Note: Make sure that the Master Dimmer channel is open in order to see the light output.

HSIC (7 CH)

7 CH
Function
(HSIC)
1 Intensity
2 Hue
3 Hue Fine
4 Saturation
5 CCT
6 Strobe
7 Control Mode
Product code: 33170
20 CH
Function
(TR16)
20 Control Mode
Value Setting
000–255 From low to high intensity (0–100 %)
000–255 From low to high intensity (0–100 %)
000–255 From low to high intensity (0–100 %)
000–255 From low to high intensity (0–100 %)
000–009 No function
010 1800 K
011-025 1800–2200 K
026–040 2200–2700 K
041–055 2700–3000 K
056–070 3000–3200 K
071–085 3200–4000 K
086–100 4000–4500 K
101–115 4500–5000 K
116–130 5000–5600 K
131–145 5600–6000 K
146–160 6000–6500 K
161–175 6500–7000 K
176–190 7000–8000 K
191–205 8000–10000 K
206–255 10000 K
000–009 No function
010–099 Strobe, from low to high frequency (0–25 Hz)
100–109 No function
110–179 Lightning strobe, from low to high frequency (0–25 Hz)
180–189 No function
190–255 Random strobe, from low to high frequency (0–25 Hz)
000–010 No Function
011–100 Reserved
101–110 Dimmer Off
111–120 Dimmer Mode 4
121–150 Reserved
151–160 1200 Hz
161–170 2400 Hz
Value Setting
190–255 Random strobe, from low to high frequency
(0–25 Hz)
000–010 No Function
011–100 Reserved
101–110 Dimmer Off
111–120 Dimmer Mode 4
121–150 Reserved
151–160 1200 Hz
161–170 2400 Hz
171–180 4000 Hz
181–190 6000 Hz
191–200 25000 Hz
201–210 All Reset
211–255 Reserved
