6.

Operation

Safety Instructions for Operation

Attention
This device must be used only for the purposes it is designed for.
This device is intended for professional use as a cyclorama wash effect. This device is not suitable for
households and for general lighting.
Any other use, not mentioned under intended use, is regarded as non-intended and incorrect use.
Attention
Power supply
Before connecting the device to the power supply, make sure that the current, voltage and frequency
match the input voltage, current and frequency specified on the information label on the device.

Control Modes

The Performer Cyc Q6 can be operated with a DMX controller and as a stand-alone device.
The Performer Cyc Q6 supports the following control modes:
● Stand-alone:
● Master/Slave:
● DMX-512, RDM
For more information about how to connect the devices, refer to 5. Setup on pages 14–16.
To operate the device manually as a stand-alone device or in a master/slave setup, adjust the levels for
red, green, blue, amber, lime and cyan in Static menu. See 6.6.1. Static Colors on page 22.
To run the built-in programs in auto operation mode, without a DMX controller:
Select one of the 10 built-in programs in Auto Program menu. See 6.6.5. Auto Programs on page 24.
Set the speed of the built-in programs in Auto Program menu. See 6.6.5. Auto Programs on page 24.
To run the preset colors without a DMX controller, select one of the 48 preset colors in Preset Color menu.
See 6.6.10. Preset Colors on page 29.
To run the custom programs, without a DMX controller:
Customize the editable programs in Edit menu. See 6.6.6. Edit on page 25.
Select one of the 2 editable programs in Auto Program menu. See 6.6.5. Auto Programs on page 24.
To operate multiple devices in the master/slave mode:
01) Use the first device as a master and use the remaining devices as slaves. See 6.6.3. Run Mode on
page 23.
02) Operate the master device in Static mode or Built-in Programs mode. See 6.6.1. Static Colors on
page 22 and 6.6.5. Auto Programs on page 24.
Product code: 33170
Static Colors, Built-in programs
Static Colors, Built-in programs
3, 7, 8, 10, 13, 20 channels
