Performer Cyc Q6

Rigging

The device can be positioned on a flat surface or be mounted on a truss or other rigging structure in any
orientation. Make sure that all loads are within the pre-determined limits of the supporting structure.
CAUTION
Restrict the access under the work area during rigging and/or derigging.
To mount the device, follow the steps below:
Fasten the quick-lock bracket (supplied with the device) on the mounting openings for the quick-
lock bracket (10) as shown in Fig. 06.
Install a clamp, as shown in Fig. 06. Make sure that you use clamps suitable for attaching the device
to the supporting structure and that the device cannot move freely.
03) Secure the device with a secondary suspension, for example a safety cable. Make sure that the
secondary suspension can hold 10 times the weight of the device. If possible, the secondary
suspension should be attached to a supporting structure independent of the primary suspension. Put
the safety cable through the safety eye (09), as shown in Fig. 06. You can use the safety cable
supplied with the device.
Product code: 33170
12
Fig. 06
