Performer Cyc Q6

DMX Error

In this submenu, you can determine the behavior of the device in case of a DMX failure.
Press the UP/DOWN buttons to toggle between the following 2 options:
SAVE:
BLACK:
Press the ENTER button to confirm.

PWM Rate

In this submenu you can set the PWM (Pulse Width Modulation) frequency. The higher the PWM
frequency, the lower the grayscale of the dimmer.
Press the UP/DOWN buttons to select a PWM frequency. The available options are: 1200 Hz, 2400 Hz,
4000 Hz, 6000 Hz and 25000 Hz.
Press the ENTER button to confirm.

Disp Key (Display Lock)

In this menu you can activate the display lock. Deactivating the display lock does not affect the
submenu items which by default require a password.
Press the UP/DOWN buttons to select ON or OFF.
ON:
The display turns off after 30 seconds of inactivity. To access the main menu, you will need
to enter the password. The default password is pressing the UP/DOWN buttons in the
following order: UP, DOWN, UP, DOWN, ENTER.
OFF:
The main menu remains unlocked after the display turns off.
Product code: 33170
The device will use the last correctly received DMX signal
The device will black out the light output
27
