Performer Cyc Q6

RDM Information

This device supports RDM. Refer to 6.9.2. Supported RDM PIDs for the Device for more information.

RDM Details

● Responder ID:
● Manufacturer's ID:
● Manufacturer Label:
● Model Description:
● Model ID:
● Device Label:
Note: An RDM responder ID consists of 3 parts:
● 1 part – 4 digits – Manufacturer's ID
st
● 2 part – 3 digits – Model ID
nd
● 3 part – 5 digits – Unique ID
rd
The RDM responder IDs of all products of Highlite International start with the same 4 digits. The first 7 digits
of the RDM responder ID for each model are the same. The last 5 digits are different for each device.

Supported RDM PIDs for the Device

Parameter ID
DISC_UNIQUE_BRANCH
DISC_MUTE
DISC_UN_MUTE
COMMS_STATUS
STATUS_MESSAGES
STATUS_ID_DESCRIPTION
CLEAR_STATUS_ID
SUPPORTED_PARAMETERS
DEVICE_INFO
DEVICE_MODEL_DESCRIPTION
MANUFACTURER_LABEL
DEVICE_LABEL
FACTORY_DEFAULTS
LANGUAGE_CAPABILITIES
LANGUAGE
SOFTWARE_VERSION_LABEL
DMX_PERSONALITY
DMX_PERSONALITY_DESCRIPTION
DMX_START_ADDRESS
SLOT_INFO
SLOT_DESCRIPTION
SENSOR_DEFINITION
SENSOR_VALUE
RECORD_SENSORS
CURVE
CURVE_DESCRIPTION
MODULATION_FREQUENCY
MODULATION_FREQUENCY_ DESCRIPTION
IDENTIFY_DEVICE
Product code: 33170
29B4:099XXXXX
Showtec (Highlite International B.V.)
Showtec
Performer CYC
153 (099 hexadecimal)
Performer CYC
Value Required
0x0001 *
0x0002 *
0x0003 *
0x0015
0x0030
0x0031
0x0032
0x0050 *
0x0060 *
0x0080
0x0081
0x0082
0x0090
0x00A0
0x00B0
0x00C0 *
0x00E0
0x00E1
0x00F0 *
0x0120
0x0121
0x0200
0x0201
0x0202
0x0343
0x0344 *
0x0347
0x0348 *
0x1000 *
36
GET SET
* *
*
*
*
*
*
*
*
* *
* *
*
* *
*
* *
*
* *
*
*
*
* *
*
* *
*
* *
*
* *
