Compact Blinder 2

Operating Determinations

 This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
 The minimum distance between light output and the illuminated surface must be bigger than 1
meter.
 The maximum ambient temperature ta = 40°C must never be exceeded.
 The relative humidity must not exceed 50 % with an ambient temperature of 40° C.
 If this device is operated in any other way than the one described in this manual, the product may
suffer damages and the warranty becomes void.
 Any other operation may lead to dangers like short-circuit, burns, electric shock, crash etc.
You endanger your own safety and the safety of others!

Rigging

Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself!
Always have the inspections carried out by an authorized dealer!
Procedure:
 If the Compact Blinder is lowered from the ceiling or high joists, professional trussing systems have to
be used.
 Use a clamp to mount the Compact Blinder, with the mounting bracket, to the trussing system.
 The Compact Blinder must never be fixed swinging freely in the room.
 The installation must always be secured with a safety attachment, e.g. an appropriate safety net or
safety cable.
 When rigging, derigging or servicing the Compact Blinder, always make sure, that the area below
the installation site is secured and that there are not any unauthorized people around.
Improper installation can cause serious injuries and/or damage of property!

Connection with the mains

Connect the device to the mains with the power-plug.
Always check if the right color cable is connected to the right place.
International
L
N
YELLOW/GREEN
Make sure that the device is always properly connected to the earth!
Improper installation can cause serious injuries and/or damage of property!
Ordercode: 30605
EU Cable UK Cable
BROWN
BLUE
US Cable
RED YELLOW/COPPER
BLACK SILVER
GREEN GREEN
4
Pin
PHASE
NEUTRAL
PROTECTIVE GROUND
