Product description
3
Product description
3.1
Product design
1
1
Important components of a measuring device
1
Electronics compartment cover
2
Display module
3
Main electronics module
4
Cable glands
5
Transmitter housing (incl. HistoROM)
6
I/O electronics module
7
Terminals (spring loaded terminals, pluggable)
8
Connection compartment cover
9
Sensor
8
2
3
9
4
5
Proline Promass F 200
6
7
8
Endress+Hauser
A0014056
