Endress+Hauser Proline Promass F 200 Brief Operating Instructions page 15

Proline Promass F 200
 3 Installation in a down pipe (e.g. for batching applications)
1 Supply tank
2 Sensor
3 Orifice plate, pipe restriction
4 Valve
5 Batching tank
[mm]
8
15
25
40
50
Endress+Hauser
1
2
3
4
5
DN
[in]
³⁄₈
½
1
1½
2
Ø orifice plate, pipe restriction
[mm]
6
10
14
22
28
Installation
A0015596
[in]
0.24
0.40
0.55
0.87
1.10
15
