Parameter Name
Input Falling Delay
Input Rising Delay

7.2 Output Signal

The device has one output signal (Line 3) and two configurable bi-directional I/Os (Line 0/1) that
can be configured to output signal, and their internal circuit is shown below.
Note
● The polarity of the device's output signal can be configured to NPN type via the client software.
The NPN internal circuit is show above.
● The max. output current is 25 mA.
Internal
Logic
Output
Level High
Output
Level Low
When the external voltage is 12 VDC and pull-up resistor is 1 KΩ, output electric feature is shown
below.
Parameter Name
Output Logic Level Low
SC2000E Series Vision Sensor Quick Start Guide
TDF
TDR
Figure 7-3 Internal Circuit of Output Signal
50%
TDF
90%
50%
10%
TF
Figure 7-4 Output Logic Level
Table 7-2 Output Electrical Feature
Parameter Symbol
VL
Parameter Symbol
15
Value
200 ns
1 μs
50%
TDR
90%
10%
TR
Value
500 mV
50%
