No.
Signal
I/O Signal Source
12
--
--
13
--
--
14
MDI0-
--
15
MDI1+
--
GPIO0
Line 0+
16
GPIO1
Line 1+
17
3.2 17-Pin Cable
You should use the supplied 17-pin cable to wire the device as shown below. The cable has a RJ45
connector that corresponds to 6th, 7th, 14th, and 15th pins of the 17-pin interface.
Note
● The open lines of the supplied 17-pin cable can be wired according to the actual demands.
● Four lines of the supplied 17-pin cable does not correspond to the device's 17-pin interface. The
black/white line is Line 0's pull-up and pull-down resistor, the pink line is Line 1's pull-up and pull-
down resistor, the orange line is Line 2's pull-up and pull-down resistor, and purple/white line is
Line 3's pull-up and pull-down resistor.
SC2000E Series Vision Sensor Quick Start Guide
--
--
Fast Ethernet signal MDI0-
Fast Ethernet signal MDI1+
Bi-directional I/O, and it is the trigger
by default.
Bi-directional I/O, and it is used to
switch project by default.
Figure 3-2 17-Pin Cable
Description
5
Supplied Cable
--
Purple open cable
RJ45 connector
RJ45 connector
Gray open cable
White open cable
