Page 1 Cayman 2E-H-W User’s Guide Release 5.6.2 November 2000...
Page 2 Copyrights Trademarks Copyright © 2000 Cayman Systems All rights reserved Printed in the United States of America Portions of this software are subject to the Mozilla Public License Version 1.1. Portions created by Netscape are copyright 1994-2000 Netscape Communications Corporation. You may obtain a copy of the license at http:// www.mozilla.org/MPL/.
Page 3: Table Of Contents
What’s New in Release 5.6.2 ......1-1 Cayman 2E-H-W Features ......1-2 Cayman 2E-H-W Front Panel .
Page 4 Entering Commands in CONFIG Mode ... . . 4-16 Displaying Current Router Settings ....4-18 Stepping Through Cayman 2E-H-W Configuration.
Page 5 Software A Technical Specifications Cayman 2E-H-W User’s Guide November 2000 Network Address Translation (NAT) Pinhole Settings . . 4-32 PPPoE Settings ......4-33 Command Line Interface Preference Settings .
Page 6 About DHCP ........C-3 Cayman 2E-H-W as DHCP Server ....C-4 Cayman 2E-H-W as DHCP Client .
Page 7: About This Manual
Cayman 2E-H-W User’s Guide November 2000 Preface This manual describes how to connect your Cayman 2E-H-W to your local area network (LAN) and wide area network (WAN) and how to conﬁgure it to function as a basestation for a wireless network and as an Ethernet hub/router.
Page 8: Documentation Conventions
Chapter 5, “Monitoring Your Cayman 2E-H-W,” describes how to monitor the performance of your Cayman 2E-H-W. Chapter 6, “Updating Your System Software,” describes how to install a new version of the Cayman 2E-H-W operating software in your router. Appendix A, “Technical Speciﬁcations,” details hardware speciﬁcations and certiﬁcations for the Cayman 2E-H-W.
Page 9 Cayman 2E-H-W User’s Guide November 2000 Alternative values for an argument are presented in curly ({ }) brackets, with values separated with vertical bars (|). Variables for which you must supply your own values are presented in italic terminal type face Notes calling attention to important points are presented in italic type with a Note icon.
Page 10 Preface Cayman 2E-H-W User’s Guide November 2000...
Page 11: What's New In Release 5.6.2
A wireless bridge that interoperates with either 802.11b or HomeRF wireless devices to create high-speed networks that do not require Ethernet cabling. An integrated eight-port Ethernet hub on the Cayman 2E-H-W front panel that lets you add or move workgroup network connections quickly and easily.
Page 12: Cayman 2E-H-W Features
SWIFT-IP™ means that installing the Cayman 2E-H-W consists of connecting the device to your networks and entering a few basic settings. You can install and conﬁgure the Cayman 2E-H-W in less than 10 minutes. Web-based browser conﬁguration makes conﬁguration and management easy from anywhere on your network.
Page 13 2E-H-W through its WAN port, limitations on packets addressed to an interface’s broadcast address, and enhanced handling of “spoofed” IP addresses. Ability to install new software images from the Cayman 2E-H-W Home page. Support for Checkpoint and Nortel Contivity virtual private networks.
Page 14: Cayman 2E-H-W Front Panel
Cayman 2E-H-W Front Panel About Your Cayman 2E-H-W The front panel of your Cayman 2E-H-W (Figure 1-1) includes the following LEDs and ports. Figure 1-1 Cayman 2E-H-W Front Panel The power LED remains steadily on when you connect your Cayman 2E-H-W to a power supply.
Page 15: Cayman 2E-H-W Back Panel
Cayman 2E-H-W User’s Guide November 2000 If you purchased the 802.11 version of the Cayman 2E-H-W the conﬁguration of the back panel of your Cayman 2E-H-W includes three ports (Figure 1-2). If you purchased the HomeRF version of the Cayman 2E-H-W, the conﬁguration of the back panel of your Cayman 2E-H-W...
Page 16 About Your Cayman 2E-H-W Cayman 2E-H-W User’s Guide November 2000...
Page 17: Unpacking Your Cayman 2E-H-W
Connecting Your Cayman 2E-H-W Disconnecting Your Cayman 2E-H-W The ﬁrst thing you should do when you receive the Cayman 2E-H-W package is conﬁrm that you have everything you should. Remove all the materials from the shipping carton and verify that you have the...
Page 18: Connecting Your Cayman 2E-H-W
2E-H-W let you connect the personal computers, printers, and other network devices in your workgroup. The 10Base-T Ethernet port on the rear panel of the Cayman 2E-H-W is used to connect the device to your corporate network, wide area network, or the Internet.
Page 19: Step 2: Connect Your Local Devices
Insert one end of a twisted-pair cable in one of the ports labeled LAN 10BT on the Cayman 2E-H-W front panel until you feel it lock (Figure 2-2). Connect the other end of the cable to the Ethernet port on a personal computer or other networked device.
Page 20: Step 3: Connect Your Wide Area Network
Setting Up Your Cayman 2E-H-W Insert one end of a twisted-pair cable in the port labeled WAN 10BT on the Cayman 2E-H-W back panel until you feel it lock (Figure 2-3). Connect the other end of the cable to the Ethernet hub, cable modem, or xDSL modem that links you to your corporate network, wide area network, or the Internet.
Page 21: Step 5: Power On The Cayman 2E-H-W
Figure 2-5 Connecting Your Cayman 2E-H-W to a Power Supply After you have connected the transformer to the Cayman 2E-H-W, plug the pronged end of the transformer cord into a 110-120 volt AC outlet (or the electrical power outlet appropriate to your location).
Page 22 Setting Up Your Cayman 2E-H-W 3. Disconnect the Cayman 2E-H-W from your local Ethernet devices. Disconnect the Ethernet cables from the LAN ports on the Cayman 2E-H-W front panel. 4. Disconnect the Cayman 2E-H-W from your WAN network. Disconnect the Ethernet cable from the WAN port on the Cayman 2E-H-W back panel.
Page 23: Gathering Configuration Information
Cayman 2E-H-W User’s Guide November 2000 Conﬁguring Your Cayman 2E-H-W Gathering Conﬁguration Information Conﬁguring Your Computer Opening a Web Connection Entering Basic Settings Entering LAN (Ethernet A) Settings Entering WAN (Ethernet B) Settings Conﬁguring Password Settings Conﬁguring Pinhole Settings Conﬁgure Wireless Settings Conﬁguring SNMP Settings...
Page 24: Quickstart Information
QuickStart Information Conﬁguring Your Cayman 2E-H-W Before you conﬁgure your Cayman 2E-H-W, you need to gather information about your networks. Most users will only need to complete the QuickStart section. For many users, the default (or factory) conﬁguration of the product will provide all the necessary services.
Page 25: Lan Port (Ethernet A) Information (Optional)
Address If you want to customize the settings for the LAN (Ethernet A) interface on your Cayman 2E-H-W, print the following table and use it to enter information in the Cayman 2E-H-W LAN Ethernet window. Some ﬁelds listed in the table only appear after you click the Expert Mode button on the Cayman 2E-H-W Home window.
Page 26 Conﬁguring Your Cayman 2E-H-W Field Name Description DHCP Mode – Disable DHCP server. (expert mode) Server – Cayman 2E-H-W uses DHCP to provide network configuration information to hosts on the Local Area Server Network. setting. Relay-agent 2E-H-W forwards DHCP requests and responses to a remote DHCP server.
Page 27: Wan (Ethernet B) Port Information (Optional)
Relay-agent is set to If you want to customize the settings for the WAN (Ethernet B) port on your Cayman 2E-H-W, print the following table and use it to enter information in the Cayman 2E-H-W Ethernet B (WAN) Conﬁguration window.
Page 28: Configuring Your Computer
IP address of the LAN interface for the Cayman 2E-H-W. 1. Conﬁgure your computer to use an IP address on the same TCP/IP network as the Cayman 2E-H-W. If you are using Windows 95/Windows 98/Windows NT: Open the Network Control Panel and select the TCP/IP service for the Ethernet card in your computer (for example, TCP/IP ->3Com EtherLink III).
Page 29 Open the TCP/IP Control Panel. b. Choose Connect via Ethernet. c. Choose Configure Using DHCP Server and enter the IP address of the Cayman 2E-H-W (192.168.1.254) in the Name Server Address text box. d. Click OK. If you are using a Macintosh running MacTCP: Open the MacTCP Control Panel and select the Ethernet interface icon.
Page 30: To Connect Over The Wireless Lan
Cayman 2E-H-W. Restart each device after you have updated its TCP/IP conﬁguration. If you want to conﬁgure your Cayman 2E-H-W from a device on your wireless local area network, you will need to install and conﬁgure the wireless network hardware and software.
Page 31 Figure 3-1 Cayman 2E-H-W Home Window (Novice Mode) If you enable PPPoE, the Cayman 2E-H-W Home window refers to the WAN port as Ethernet B (PPPoE) instead of Ethernet B (WAN) (Figure 3-2).
Page 32 Conﬁguring Your Cayman 2E-H-W 3-10 4. Use the buttons on the Cayman 2E-H-W Home Page to issue a command or open a window. The Quickstart button opens the QuickStart window, which lets you enter basic settings for your Cayman 2E-H-W.
Page 33: Entering Basic Settings
IP address information for the device's WAN (Ethernet B) port, the Cayman 2E-H-W QuickStart window asks you only for the name you want to assign your Cayman 2E-H-W. If you have overridden the default settings for IP address information for...
Page 34: Manual Quickstart
1. Enter the name of your Cayman 2E-H-W in the System Name ﬁeld. Each Cayman 2E-H-W is assigned a name as part of its factory initialization. The default name for a Cayman 2E-H-W consists of the word “Cayman-2E” and the serial number of the device.
Page 35 1. Enter the name of your Cayman 2E-H-W in the System Name ﬁeld. Each Cayman 2E-H-W is assigned a name as part of its factory initialization. The default name for a Cayman 2E-H-W consists of the word “Cayman-2E” and the serial number of the device. A device name can be 1-32 characters long and cannot include spaces or special characters.
Page 36 5. Enter the IP address of the default gateway for your network in the Default Gateway ﬁeld. The default gateway is the host to which the Cayman 2E-H-W will send packets if it does not know how to reach a destination host.
Page 37: Quickstart (Pppoe On)
2E-H-W Home Page to restart your Cayman 2E-H-W with its new conﬁguration. If your Cayman 2E-H-W is conﬁgured to use PPPoE (PPP over Ethernet) framing, the PPPoE QuickStart window (Figure 3-6) opens when you click the QuickStart button on the Cayman 2E-H-W Home Page.
Page 38 PPP link is being established in the PPP Username ﬁeld. This is the username the Cayman 2E-H-W sends in a PAP or CHAP response packet. The information you enter must match the CHAP username conﬁgured in the remote PPP peer's authentication database.
Page 39: Entering Lan (Ethernet A) Settings
TCP/IP addresses. If your network falls into this category, do not change the LAN Ethernet settings. To display the Ethernet Port (LAN) Conﬁguration window (Figure 3-7), click the Ethernet A (LAN) button on the Cayman 2E-H-W Home Page. Figure 3-7 Ethernet Port (LAN) Conﬁguration Window (expert mode)
Page 40 Most sites should use 255.255.255.0 for their subnet mask. If you have turned on Expert Mode on the Cayman 2E-H-W Home window, you will see a set of DHCP ﬁelds on the Ethernet Port Conﬁguration (LAN) window. If you did not turn on Expert Mode, you can skip to Step 8, below.
Page 41: Entering Wan (Ethernet B) Settings
Cayman 2E-H-W. The appearance of the Ethernet B window depends on whether you have turned on PPP over Ethernet on the port. The Cayman 2E-H-W is conﬁgured at the factory to determine the correct conﬁguration for its WAN port automatically. You will only Conﬁguring Your Cayman 2E-H-W...
Page 42: Pppoe Is Off
If you want your Cayman 2E-H-W to acquire the IP address for its WAN port from a DHCP server on your wide area network, enter 0.0.0.0...
Page 43: Pppoe Is On
The subnet mask speciﬁes which bits of the 32-bit binary IP address represent network information. Most sites should use for their subnet mask. 255.255.255.0 If you want your Cayman 2E-H-W to acquire the subnet mask for its WAN port from a DHCP server on your backbone network, enter 0.0.0.0 3.
Page 44 3. Specify whether you want the connection to be maintained constantly or only when it is needed. If you choose a connection type of Instant On, the Cayman 2E-H-W shuts down the PPP link if it is not being used for the Cayman 2E-H-W User’s Guide November 2000...
Page 45 November 2000 number of seconds speciﬁed in the Idle Timeout ﬁeld. If you choose a connection type of Always On, the Cayman 2E-H-W keeps the PPP link open at all times. 4. If you speciﬁed a connection type of Instant On, specify...
Page 46: Configuring Password Settings
Cayman 2E-H-W. You must assign the Cayman 2E-H-W an Admin password before you can assign it a User password. You will see a warning on the Cayman 2E-H-W conﬁguration screens until you set an administrative password. To prevent anyone from observing the password you enter, characters in the old and new passwords are not displayed as you type them.
Page 47 Cayman 2E-H-W User’s Guide November 2000 To display the Password Conﬁguration window (Figure 3-10), click the Passwords button on the Cayman 2E-H-W Home Page. You must be in Expert Mode to open the Password Conﬁguration window. Figure 3-10 Password Conﬁguration Window To conﬁgure passwords for your Cayman 2E-H-W:...
Page 48: Configuring Pinhole Settings
To display the Pinhole Conﬁguration window (Figure 3-11), click the Pinhole button on the Cayman 2E-H-W Home Page. You must be in Expert Mode to open the Pinhole Conﬁguration window. Cayman 2E-H-W User’s Guide...
Page 49 After you have made this change, you will need to use this port number to open a Web connection to the Cayman 2E-H-W. For example, if you change the Web-HTTP port to 1080 on a Cayman 2E-H-W using its default IP address ), you would open a web connection to the 192.168.1.254...
Page 50 Telnet connection to the Cayman 2E-H-W. For example, if you change the Telnet port to 1023 on a Cayman 2E-H-W using its default IP address ), you would open a Telnet connection to the 192.168.1.254...
Page 51 Cayman 2E-H-W User’s Guide November 2000 7. Use the Protocol dropdown menu to select the type of protocol (TCP, UDP, ICMP, or PPTP) you want to redirect. If you want to redirect a protocol type other than TCP, UDP, ICMP, or PPTP, use the second line of the table to enter the protocol type name.
Page 52: Configuring Wireless Settings
2E-H-W Home Page to restart your Cayman 2E-H-W with its new conﬁguration. You can use your Cayman 2E-H-W as a basestation for HomeRF or 802.11 wireless networking. Your Cayman 2E-H-W bridges your wireless network functions to your Ethernet local area network, letting computers on the wireless network access the Internet and share LAN resources such as printers and servers.
Page 53: 802.11 Settings
To display the Wireless Setup window for 802.11 wireless networking (Figure 3-13), click the Wireless button on the Cayman 2E-H-W Home Page. You must be in Expert Mode to open the Wireless Setup window. Conﬁguring Your Cayman 2E-H-W...
Page 54 2. Specify the radio channel you want your Cayman 2E-H-W to use by entering a number in the range 1-11 in the Default Channel ﬁeld. By default, your Cayman 2E-H-W uses channel 7, which uses a frequency of 2442MHz. You should not change this channel Cayman 2E-H-W User’s Guide...
Page 55 Cayman 2E-H-W User’s Guide November 2000 unless you are using more than one Cayman 2E-H-W in the same area. The following table lists the frequencies associated with 802.11 channels and the regions for which each channel is authorized. Channel Frequency...
Page 56: Configuring Snmp Settings
SNMP Setup window lets you enter SNMP conﬁguration information for your Cayman 2E-H-W. To display the SNMP Setup window (Figure 3-14), click the SNMP button on the Cayman 2E-H-W Home Page. You must be in Expert Mode to open the SNMP Setup window. Cayman 2E-H-W User’s Guide...
Page 57 3. Click the Save button to store your modiﬁed conﬁguration in the Cayman 2E-H-W memory. 4. If you want the Cayman 2E-H-W to use authentication traps, click the Authentication Traps On radio button. If SNMP trapping is enabled, your Cayman 2E-H-W sends authentication traps to all SNMP trap destinations.
Page 58 5. Identify the SNMP communities to which the Cayman 2E-H-W belongs by entering a community name in the Communities ﬁeld and clicking the Add button. By default, the Cayman 2E-H-W is associated with the public community. You can associate as many as 16 communities with the Cayman 2E-H-W.
Page 59: Using The Command Line Interface
The Cayman 2E-H-W operating software includes a command line interface (CLI) that lets you monitor and conﬁgure your Cayman 2E-H-W over a Telnet or console connection. You can use the command line interface to enter and update a Cayman 2E-H-W’s conﬁguration settings, monitor its performance, and restart it.
Page 60 Using the Command Line Interface telnet ip_address You must know the IP address of the Cayman 2E-H-W before you can make a Telnet connection to it. By default, your Cayman 2E-H-W uses 192.168.1.254 as the IP address for its LAN interface. You can use a Web browser or the maintenance console to conﬁgure the Cayman...
Page 61 Logging In The command line interface log-in process emulates the log-in process for a UNIX host. If your Cayman 2E-H-W has been assigned an administrator password or user password, you must enter a username (up to 32 characters) and your password.
Page 62: Using The Cli Help Facility
You can save the changes you have entered for a speciﬁc function or for all functions in the Cayman 2E-H-W. The Cayman 2E-H-W automatically validates its settings when you save and displays a warning message if the conﬁguration is not correct.
Page 63: Root Command Shortcuts
Sends an Address Resolution Protocol (ARP) request to match the IP address to an Ethernet hardware address. nnn.nnn.nnn.nnn clear [yes] Clears the conﬁguration settings in a Cayman 2E-H-W. If you do not use the optional qualiﬁer, you are prompted to conﬁrm the command.
Page 64 If you omit arguments, the console prompts you for this information. argument identiﬁes the IP address of the server_address TFTP server from which you want to copy the Cayman 2E-H-W conﬁguration ﬁle. argument identiﬁes the path and name of the filename conﬁguration ﬁle on the TFTP server.
Page 65 The TFTP server must be accessible on your Ethernet network. The argument identiﬁes the IP address of the TFTP server_address server on which your Cayman 2E-H-W operating software is stored. argument identiﬁes the path and name of the filename operating software ﬁle on the TFTP server.
Page 66 [-s size [-c count { hostname | ip_address } Causes the Cayman 2E-H-W to issue a series of ICMP Echo requests for the device with the speciﬁed name or IP address. argument is the name of the device you want to hostname ping;...
Page 67 Clears crash-dump information, which identiﬁes the contents of the Cayman 2E-H-W registers at the point of system malfunction. reset dhcp client release Releases the DHCP lease the Cayman 2E-H-W is currently using to acquire the IP settings for its WAN (Ethernet B) port. reset dhcp client renew Renews the DHCP lease the Cayman 2E-H-W is currently using to acquire the IP settings for its WAN (Ethernet B) port.
Page 68 [seconds] Restarts your Cayman 2E-H-W. If you include the optional argument, your Cayman 2E-H-W will restart when the speciﬁed number of seconds have elapsed. You must enter the complete command to initiate a restart.
Page 69 You can include the argument to see the list of DHCP leases that used are in use or that have been used since your Cayman 2E-H-W was restarted. You can include the leases that are available for use. show dhcp server store Displays the DHCP leases stored in NVRAM by your Cayman 2E-H-W.
Page 70 Displays the current status of a Cayman 2E-H-W, the device's hardware and software revision levels, a summary of errors encountered, and the length of time the Cayman 2E-H-W has been running since it was last restarted. Identical to the show wireless Displays status and statistics information for the wireless interface on your Cayman 2E-H-W.
Page 71 Telnet session. traceroute { hostname | ip_address } Lets you trace the route between the Cayman 2E-H-W and the speciﬁed host. argument is the name of the device you want to hostname trace;...
Page 72: About Config Commands
Displays the names of the current shell users. wireless learn Lets you put your Cayman 2E-H-W into Learn mode for 60 seconds, allowing it to acquire its network address from a HomeRF device in Teach mode on your network. Only supported for HomeRF.
Page 73: Navigating The Config Hierarchy
Navigating the CONFIG Hierarchy Cayman 2E-H-W User’s Guide November 2000 Moving from CONFIG to ROOT — You can navigate from anywhere in the CONFIG hierarchy back to the ROOT level by entering at the CONFIG prompt and pressing R quit Dogzilla (top)>>...
Page 74: Entering Commands In Config Mode
A address 192.31.222.57 , and ) and two ethernet address ). When you use the Cayman 2E-H-W User’s Guide November 2000...
Page 75 Cayman 2E-H-W User’s Guide November 2000 The following table provides guidelines for entering and formatting CONFIG commands. Command Rules for entering CONFIG commands component Command verbs CONFIG commands must start with a command verb (set, view, delete). You can truncate CONFIG verbs to three characters (set, vie, del).
Page 76: Displaying Current Router Settings
If you enter the intermediate node, you see settings for that node and its subnodes. The Cayman 2E-H-W command line interface includes a step mode to automate the process of entering conﬁguration settings. When you use the CONFIG step mode, the command line interface prompts you for all required and optional information.
Page 77: Validating Your Configuration
Bridging lets the Cayman 2E-H-W use MAC (Ethernet hardware) addresses to forward non-TCP/IP trafﬁc from one network to another. When bridging is enabled, the Cayman 2E-H-W maintains a table of up to 255 MAC addresses. Entries that are not used within 10 minutes are dropped.
Page 78: Dhcp Settings
A device that acquires its IP address and other TCP/IP conﬁguration settings from the Cayman 2E-H-W can use the information for a ﬁxed period of time (called the DHCP lease). set dhcp option { off | server | relay-agent } Enables or disables DHCP services in the Cayman 2E-H-W.
Page 79: Domain Name System Settings
{ on | off } Enables or disables your ability to override the Ethernet MAC address for the WAN port on your Cayman 2E-H-W. You must enable the dd:hh:mm:ss , speciﬁes the IP address in the remote...
Page 80: Ip Settings
You can use the command line interface to specify whether TCP/IP is enabled, identify a default gateway, and to enter TCP/IP settings for the Cayman 2E-H-W LAN and WAN ports. If PPPoE is turned off, you must specify settings for Ethernet A and B separately. if PPPoE is turned on, you can omit the A|B labels.
Page 81 Cayman 2E-H-W User’s Guide November 2000 unique on your network. By default, the Cayman 2E-H-W uses 192.168.1.254 as its LAN IP address. set ip ethernet [ A | B ] broadcast broadcast_address Speciﬁes the broadcast address for the TCP/IP network connected to the designated Ethernet port.
Page 82 4-24 set ip ethernet [ A | B ] proxy-arp { on | off } Speciﬁes whether you want the Cayman 2E-H-W to respond when the it receives an address resolution protocol for devices behind it. By default, proxy ARP is turned off.
Page 83: Default Ip Gateway Settings
2E-H-W receives a RIP packet, it uses the expected key to create an MD-5 digest of the RIP message. It then compares this calculated digest to the MD-5 digest sent with the RIP packet. If the calculated digest does not match the received digest, the RIP message is discarded.
Page 84: Ip-Over-Ppp Settings
PPP interface will use the IP address assigned to it by the remote peer. Note that the remote peer must be conﬁgured to supply an IP address to your Cayman 2E-H-W if you enter 0.0.0.0 for the...
Page 85 { none | admin-disabled | admin-only } Speciﬁes restrictions on the types of trafﬁc the Cayman 2E-H-W accepts over the PPP virtual circuit. The all trafﬁc is accepted. The admin-disabled router trafﬁc is accepted but that administrative commands are...
Page 86: Static Route Settings
ARP table entries, static ARP table entries do not time out. You can conﬁgure as many as 16 static ARP table entries for a Cayman 2E-H-W. Use the following commands to add static ARP entries to the Cayman 2E-H-W static ARP table: set ip static-arp ip-address ip_address Speciﬁes the IP address for the static ARP entry.
Page 87 Cayman 2E-H-W User’s Guide November 2000 You can conﬁgure as many as 16 static IP routes for a Cayman 2E-H-W. Use the following commands to maintain static routes to the Cayman 2E-H-W routing table: set ip static-routes destination-network net_address Speciﬁes the network address for the static route. Enter a network address in the argument in dotted decimal format.
Page 88: Wan Settings
WAN port before you can conﬁgure its network settings. set ip wan address ip_address Assigns an IP address to the Cayman 2E-H-W on the wide area network. The IP address you assign to an Ethernet port must be unique on your network.
Page 89: Network Address Translation (Nat) Default Settings
By default, proxy ARP is turned off. NAT default settings let you specify whether you want your Cayman 2E-H-W to forward NAT trafﬁc to a default server when it doesn’t know what else to do with it. The NAT default host function is useful in situations where you cannot create a speciﬁc NAT pinhole for a...
Page 90: Network Address Translation (Nat) Pinhole Settings
Pinhole Settings Using the Command Line Interface 4-32 otherwise be discarded by the Cayman 2E-H-W should be directed to a speciﬁc hosts. set nat-default option { off | on } Speciﬁes whether you want your Cayman 2E-H-W to forward NAT trafﬁc to a default server when it doesn’t know what else to do with...
Page 91: Pppoe Settings
PPP over Ethernet on your Cayman 2E-H-W. set pppoe { on | off } Enables or disables PPP over Ethernet on your Cayman 2E-H-W. You must enable PPPoE before you can enter other PPP settings. Using the Command Line Interface...
Page 92 Speciﬁes whether you want your Cayman 2E-H-W to send LCP echo requests. By default, LCP echoing is turned on. You should turn off LCP echoing if you do not want the Cayman 2E-H-W to drop a PPP link to a nonresponsive peer.
Page 93: Port Authentication
PPP module connection-type [ instant-on | always-on ] Speciﬁes whether a PPP connection is maintained by the Cayman 2E-H-W when it is unused for extended periods. If you specify , the Cayman 2E-H-W never shuts down the PPP link. If...
Page 94 As a result, the port authentication names for PAP and CHAP must be identical to the peer names for your Cayman 2E-H-W on the remote peer. If you do not conﬁgure a chap-name or pap-name, then the authentication packets sent by the local peer will have blank name values.
Page 95: Peer Authentication
PAP password used by the PPP peer. Peer Authentication You can specify that your Cayman 2E-H-W will use PAP, CHAP, or both to authenticate a remote peer as a PPP link is being completed. Perform the following steps to specify how your Cayman 2E-H-W should authenticate remote peers.
Page 96: Command Line Interface Preference Settings
16 lines of text before displaying the prompt More …[y|n] ?. If you enter 0 for the lines argument, the command line interface displays information as an uninterrupted stream (which is useful for capturing information to a text ﬁle). Cayman 2E-H-W User’s Guide November 2000...
Page 97: Port Renumbering Settings
November 2000 If you use NAT pinholes to forward HTTP or Telnet trafﬁc through your Cayman 2E-H-W to an internal host, you must change the port numbers the Cayman 2E-H-W uses for its own conﬁguration trafﬁc. For example, if you set up a NAT pinhole to forward network trafﬁc on Port 80 (HTTP) to another host, you would have to tell the Cayman 2E-H-W to listen for conﬁguration connection requests on a...
Page 98 Identiﬁes the location, such as the building, ﬂoor, or room number, of the Cayman 2E-H-W. You can enter up to 256 characters for the argument. You must put the location_info argument in double-quotes if it contains embedded spaces.
Page 99: System Settings
1-16 characters long and cannot include spaces or special characters. Once you have assigned a name to your Cayman 2E-H-W, you can enter that name in the Open Location text ﬁeld of your browser to open a connection to your Cayman 2E-H-W.
Page 100: Traffic Shaping Settings
Passwords are case-sensitive and cannot include special characters or leading, trailing, or embedded spaces. For example, if you assign a password of “GatoR” to a Cayman 2E-H-W, you could not enter “GATOR”, “gator”, “Gator”, or “GatoR ” (with a trailing space) as an acceptable password.
Page 101: Wireless Settings (Homerf)
Options are 56000, 384000, and 1000000. set wireless id identifier Speciﬁes the name of the Cayman 2E-H-W on your wireless network. The default HomeRF wireless ID for a Cayman 2E-H-W consists of two four-digit numbers, which are located on the label on the bottom of your Cayman 2E-H-W.
Page 102 0x1234567890ABCDEF1234567890 set wireless authentication-type [ open | shared-key ] If WEP is enabled, this determines whether or not a wireless client on your network can connect to the Cayman 2E-H-W. If you select Cayman 2E-H-W User’s Guide November 2000...
Page 103 Cayman 2E-H-W User’s Guide November 2000 Open authentication, any client can connect. If you select Shared authentication, the client must have the same exact encryption keys to pass authentication. Using the Command Line Interface 4-45...
Page 104 Using the Command Line Interface Cayman 2E-H-W User’s Guide 4-46 November 2000...
Page 105 Cayman 2E-H-W User’s Guide November 2000 Monitoring Your Cayman 2E-H-W Displaying the Overview Status Displaying the Diagnostic Log Displaying IP ARP Statistics Displaying IP Interface Statistics Displaying IP Routes Displaying DHCP Server Statistics Displaying DHCP Client Statistics Displaying Memory Statistics...
Page 106: Displaying The Overview Status
Monitoring Your Cayman 2E-H-W The Monitor window lets you display information about the status of your Cayman 2E-H-W. To open the Monitor window, run your web browser and open a connection to your Cayman 2E-H-W, and then click the Monitor button on the Cayman 2E-H-W Home Page. When the Monitor window opens, click the button for the type of information you want.
Page 107: Displaying The Diagnostic Log
Diagnostic Log Cayman 2E-H-W User’s Guide November 2000 Your Cayman 2E-H-W maintains a log ﬁle consisting of diagnostic and error messages it generates during operation. The Diagnostic Log window displays the contents of the Cayman 2E-H-W diagnostic log. To display the Diagnostic Log window, click the Show button on the Monitor window.
Page 108: Displaying Ip Arp Statistics
Statistics Monitoring Your Cayman 2E-H-W The IP ARP table displays the static and dynamic address resolution information maintained by the Cayman 2E-H-W. To display the IP ARP Statistics window, click the IP ARP button on the Monitor window. Figure 5-3.
Page 109: Displaying Ip Interface Statistics
Statistics Cayman 2E-H-W User’s Guide November 2000 The IP Interfaces monitor window displays information about the Ethernet ports on your Cayman 2E-H-W. To display the IP Interfaces Statistics window, click the IP Interfaces button on the Monitor window. Figure 5-4.
Page 110: Displaying Ip Routes
Routes Monitoring Your Cayman 2E-H-W The IP Routes window displays information about the IP routes stored in your Cayman 2E-H-W. To display the IP Routes window, click the IP Routes button on the Monitor window. Figure 5-5. IP Routes Monitor Cayman 2E-H-W User’s Guide...
Page 111: Displaying Dhcp Server Statistics
The DHCP monitor window displays the Ethernet hardware address that corresponds to each IP address your Cayman 2E-H-W has assigned to a device on your network. To display the DHCP Server Statistics window, click the DHCP Server button on the Monitor window.
Page 112: Displaying Dhcp Client Statistics
Displaying DHCP Client Statistics Monitoring Your Cayman 2E-H-W As a DHCP client, your Cayman 2E-H-W can accept IP address information from a DHCP server on your network. To display the DHCP Client Statistics window, click the DHCP Client button on the Monitor window.
Page 113: Displaying Memory Statistics
Statistics Cayman 2E-H-W User’s Guide November 2000 The Memory monitor window displays information about memory allocation in your Cayman 2E-H-W. To display the Memory monitor window, click the Memory button on the Monitor window. Figure 5-8. Memory Monitor Monitoring Your Cayman 2E-H-W...
Page 114: Displaying Ethernet Statistics
Statistics Monitoring Your Cayman 2E-H-W 5-10 The Ethernet Statistics monitor window displays information about each Ethernet interface for your Cayman 2E-H-W. To display the Ethernet Statistics window, click the Ethernet button on the Monitor window. Figure 5-9. Ethernet Statistics Monitor Cayman 2E-H-W User’s Guide...
Page 115: Displaying Pppoe Statistics
Displaying PPPoE Statistics Cayman 2E-H-W User’s Guide November 2000 The PPPoE Statistics window displays information about the PPPoE trafﬁc on your network. To display the PPPoE Statistics window, click the PPPoE button on the Monitor window. Figure 5-10. PPPoE Statistics Monitors...
Page 116: Displaying Wireless Statistics
Statistics Monitoring Your Cayman 2E-H-W 5-12 The Wireless Statistics window displays information about the wireless network trafﬁc maintained by your Cayman 2E-H-W. To display the Wireless Statistics window, click the Wireless button on the Monitor window. Figure 5-11 Wireless Statistics (HomeRF) Figure 5-12 Wireless Statistics Window (802.11b)
Page 117: Using The Diagnose Utility
November 2000 The Diagnose utility runs a series of internal checks and loopback tests to verify network connectivity over each interface on your Cayman 2E-H-W. To run the Diagnose utility, click the Diagnose button on the Monitor window. Figure 5-13...
Page 118 Monitoring Your Cayman 2E-H-W Cayman 2E-H-W User’s Guide 5-14 November 2000...
Page 119: Updating Your System Software
Using TFTP to Install a New Image You can install a new operating system image in your Cayman 2E-H-W from the Home Page. To do so, the computer you are using to install the new image must be connected to the LAN interface of the Cayman 2E-H-W.
Page 120 If you have not previously saved your conﬁguration (that is, if you are running the factory default conﬁguration your Cayman 2E-H-W came with), click the Ethernet button on the Cayman 2E-H-W home page. When the Ethernet window appears, click Save.
Page 121: Using The Installer To Install A New Image
You must run the Installer utility from a computer running Windows 95, Windows 98, or Windows NT on the Cayman 2E-H-W local area network. To install new operating system software in your Cayman 2E-H-W from a Windows computer: 1.
Page 122 Cayman from the Start menu and choose the Installer program. 9. When the Installation Target Selection window appears, enter the name or IP address of your Cayman 2E-H-W in the IP Address or Name text ﬁeld. The default IP address is 10.
Page 123: Using Tftp To Install A New Image
Image Cayman 2E-H-W User’s Guide November 2000 You can install new operating system software in a Cayman 2E-H-W from any computer capable of functioning as a Trivial File Transfer Protocol (TFTP) server. Your TFTP server must be on the same Ethernet network as the LAN interface of your Cayman 2E-H-W.
Page 124 Updating Your System Software Cayman 2E-H-W User’s Guide November 2000...
Page 125: Technical Specifications
Cayman 2E-H-W User’s Guide November 2000 Technical Speciﬁcations Technical speciﬁcations and certiﬁcations subject to change. Changes or modiﬁcations not expressly approved by your authorized Cayman 2E-H-W reseller can void your authority to operate the equipment. Processor Motorola MPC 850 Memory...
Page 126: Interfaces
Radius of 150 feet Shared Wireless Access Protocol (SWAP) 11, 5.5, 2, and 1 Mbps per channel, auto fall-back 2.4–2.483 GHz (Direct Sequence Spread Spectrum) 13 dBm Radius of 460 feet for 11Mbps in open environment Cayman 2E-H-W User’s Guide November 2000...
Page 127: Certifications
Certiﬁcations FCC Class B Notice Canadian Interference Notice Cayman 2E-H-W User’s Guide November 2000 ETL to UL 1950 cETL to CSA C22.2 No. 950 CE Markings to: EN60950/A3:1995 EN55022:1994 Class A EN50082-1:1992 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 128 Technical Speciﬁcations Cayman 2E-H-W User’s Guide November 2000...
Page 129: Diagnostic Console
Cayman 2E-H-W maintenance console port and restarting into diagnostic (EPROM) mode. To use the Cayman 2E-H-W diagnostic console, you need a serial cable and either a terminal or terminal emulator (such as a personal computer with a terminal emulation application that supports 9600-baud communication).
Page 130: Connecting A Terminal To The Console Port
Terminal to the Console Port Diagnostic Console To connect your Cayman 2E-H-W to a terminal or terminal emulator: 1. Turn off the Cayman 2E-H-W. 2. Plug one end of the serial cable into the maintenance console port on the Cayman 2E-H-W back panel.
Page 131: Using The Diagnostic Console
When you ﬁnish using the diagnostic console, turn your Cayman 2E-H-W off and on to return it to normal operation. This section presents the commands you will use to enter, modify, or clear settings in the Cayman 2E-H-W EPROM.
Page 132: Basic Commands
2E-H-W to their factory default values. After you reset the Cayman 2E-H-W EPROM values to their defaults, you must save them to non-volatile storage with the The default boot settings for the Cayman 2E-H-W are presented in the following table. Setting Explanation Use the image in flash memory if possible.
Page 133: Administration Commands
[nogo] If you do not enter an argument, the Cayman 2E-H-W to behave as if it had been powered up with autoboot enabled. That is, it will try to download its image from ﬂash, TFTP, and BOOTP (if enabled) in that order.
Page 134 ﬂash (not the EPROM erase options settings). Compare to the current and non-volatile copies of the Cayman 2E-H-W EPROM settings. clears the setting headers, which is a quick way erase headers of invalidating the code ﬂash and forcing an image download.
Page 135: Boot Setting Commands
{ retry_count | off } command (where autoboot retry_count whole number) sets the number of times the Cayman 2E-H-W should attempt to start an image and run it when powered up. If you enable autoboot with the autoboot retry_count...
Page 136 1. If ﬂash is enabled, start an image from the Cayman 2E-H-W code ﬂash memory, using the conﬁgured image number; else 2. If ip is enabled, load an image via IP TFTP using the conﬁgured IP server, IP gateway, netmask and ﬁlename;...
Page 137 ARP cache inconsistencies on your IP hosts. ipgateway ip_address command speciﬁes the IP address of the ipgateway ip_address router (if any) between the Cayman 2E-H-W and its IP TFTP server in dotted decimal notation. Enter gateway function. ipnetmask netmask command speciﬁes the subnet mask for ipnetmask netmask your IP interface in dotted decimal format.
Page 138 Diagnostic Console Cayman 2E-H-W User’s Guide B-10 November 2000...
Page 139: About Bridging
Ethernet network connected to its LAN interface from routers on networks connected to its WAN interface. When NAT is enabled, the Cayman 2E-H-W “proxies” for computers on your network by pretending to be the originating host for network communications from non-originating networks.
Page 140: Tcp/Ip Routing
Bridges let you join two local area networks, so that they appear to be part of the same physical network. As a bridge for protocols other than TCP/IP, your Cayman 2E-H-W keeps track of as many as 255 MAC (Ethernet hardware) addresses, each of which uniquely identiﬁes an individual host on a network.
Page 141: About Dhcp
MAC address and the interface appropriate for reaching that host to its bridging table. The Cayman 2E-H-W tracks the age of each entry in its bridging table, and deletes entries that aren't used after 10 minutes. If more than 255 entries are active at the same time, the Cayman 2E-H-W discards the oldest entries to make room for new ones.
Page 142: Cayman 2E-H-W As Dhcp Server
IP addresses among a group of clients that do not need permanent IP addresses. The Cayman 2E-H-W is conﬁgured at the factory to act as a DHCP client on its WAN port. This means that, if substitute IP address information is not conﬁgured for the WAN port, the Cayman 2E-H-W...
Page 143: About Ppp
TCP/IP hosts and networks over a serial telephone connection (applicable to older versions of the Cayman 2E-H-W) or an Ethernet (xDSL or cable modem) connection. Extensions to the PPP protocol suite enable a PPP link to support other network protocols, including IPX, AppleTalk, and DECnet.
Page 144: Link Establishment
Ethernet port is conﬁgured as a dial-in, dial-out, or dedicated PPP interface: Dial-in – If a port is conﬁgured as a dial-in interface, the router sends an initialization string to the modem when it is turned on to prepare it to accept calls.
Page 145 1500), then Peer A can send frames up to 1500 bytes long to Peer B but Peer B can send frames up to 1492 bytes long to Peer A. How Your Cayman 2E-H-W Works...
Page 146 If you specify that a serial port can use either CHAP or PAP to authenticate a remote peer (that is, both CHAP and PAP are enabled), the router tries to use CHAP to authenticate connection requests. If the remote peer does not support CHAP, the router requires that the remote peer use PAP to authenticate itself.
Page 147: Network Configuration
A link can be terminated during initialization because a conﬁguration or authentication failure occurs. Once a PPP link is established, it remains conﬁgured for communication unless explicit LCP or NCP packets close the link or until some external event, such as the How Your Cayman 2E-H-W Works...
Page 148: Ppp And Routing Tables
Your Cayman 2E-H-W maintains a routing table for its IP routing service. The routing table identiﬁes the networks a router can reach, the interface and gateway through which the router must forward a...
Page 149: Dealing With Unavailable Routes
A route to a network connected directly to the router has a metric of 1, a route to a network reachable through one other gateway has a metric of 2, and so on.
Page 150 How Your Cayman 2E-H-W Works C-12 Timing out – When a router adds a dynamic route to its routing table, it starts a timer for that route. This timer is restarted whenever the router receives another RIP packet advertising the router.
Page 151: About Ppp Over Ethernet (Pppoe
The Discovery stage of a PPPoE session consists of four steps: 1. Initiation – When a host wants to open a PPPoE session, it sends out a PPPoE Active Discovery Initiation (PADI) broadcast asking any available Access Concentrators to respond. If a host How Your Cayman 2E-H-W Works C-13...
Page 152 How Your Cayman 2E-H-W Works C-14 does not receive a response within the timeout period, it resends its PADI packet and doubles its timeout period. 2. Offer – If an Access Concentrator for the network can serve the request, it sends a PPPoE Active Discovery Offer (PADO) packet to the host identifying its name and the services it can offer to the host.
Page 153: About Wireless Networking
When you install a Cayman 2E-H-W as part of a wireless network, the Cayman 2E-H-W connects to a wired local area network using standard Ethernet wiring. To use the wireless network, a user installs a wireless-LAN adapter (such as a PCMCIA card) in a computer and identiﬁes the Cayman 2E-H-W with which the computer should...
Page 154 How Your Cayman 2E-H-W Works Cayman 2E-H-W User’s Guide C-16 November 2000...
Page 155: Glossary
ADSL ANSI ASCII Cayman 2E-H-W User’s Guide November 2000 Glossary IEEE 802.3 speciﬁcation for Ethernet that uses thin coaxial cable to run at 10 Mbps. Limited to 185 meters per segment. 10Base5 IEEE 802.3 baseband physical layer speciﬁcation for Ethernet that uses thick coaxial cable to run at 10 Mbps.
Page 156 Storage area used to hold data until it can be forwarded. Signal suitable for transmission of information. Comité Consultatif International Télégraphique et Téléphonique or Consultative Committee for International Telegraph and Telephone. An international organization responsible for developing telecommunication standards. Carrier Detect. Cayman 2E-H-W User’s Guide November 2000...
Page 157 CSU/DSU data bits datagram dedicated line Cayman 2E-H-W User’s Guide November 2000 Challenge-Handshake Authentication Protocol. Security protocol in PPP that prevents unauthorized access to network services. See RFC 1334 for PAP speciﬁcations Compare PAP. Network node that requests services from a server.
Page 158 Glossary Dynamic Host Conﬁguration Protocol. A network conﬁguration protocol that lets a router or other device assign IP addresses and supply other network conﬁguration information to computers on your network. Port setting that speciﬁes that other routers can initiate a connection to the local router but that the local router cannot initiate a connection to other routers.
Page 159 FTP server hardware handshake HDLC HDSL header Cayman 2E-H-W User’s Guide November 2000 Technique used to enclose information formatted for one protocol, such as AppleTalk, within a packet formatted for a different protocol, such as TCP/IP. The application of a speciﬁc algorithm to a data set so that anyone without the encryption key cannot understand the information.
Page 160 Random number generated by a router and included in packets it sends to other routers. If the router receives a packet with the same magic number it is using, the router sends and receives packets with new random numbers to determine if it is talking to itself.
Page 161 November 2000 Distance, measured in the number of routers a packet must traverse, that a packet must travel to go from a router to a remote network. A route with a low metric is considered more efﬁcient, and therefore preferable, to a route with a high metric. See hop count.
Page 162 Table stored in a router or other networking device that records available routes and distances for remote network destinations. Request to Send. Circuit activated in hardware ﬂow control when a computer (or other DTE) is ready to transmit data to a modem (or other DCE).
Page 163 T1 link Telnet twisted pair xon/xoff Cayman 2E-H-W User’s Guide November 2000 A 32-bit address mask that identiﬁes which bits of an IP address represent network address information and which bits represent node identiﬁer information. Method of data communication requiring the transmission of timing signals to keep PPP peers synchronized in sending and receiving blocks of data.
Page 164 Glossary Cayman 2E-H-W User’s Guide November 2000...
Page 165 CLI 4-16 arp command 4-5 ARP table 5-4 ARP, proxy 4-24, 4-31 authentication trap 3-35, 4-39 autoboot command B-7 back panel, Cayman 2E-H-W 1-5 bandwidth shaping 1-3 boot command B-5 bootp command B-8 bridging 4-19, C-2 broadcast address 4-23, 4-30...
Page 166 DHCP relay-agent lease 4-10 Diagnose utility 1-3, 5-13 diagnostic console B-1 diagnostic log 4-7, 4-10, 4-11, 5-3 diagnostic log level 4-41 disconnecting your Cayman 2E-H-W 2-5 DNS 4-21 domain name 3-14, 4-21 Index domain name server 3-14 Domain Name System (DNS) 4-21...
Page 167 3-18 LAN port 1-5 lease 4-10 lease time 3-18, 4-21 power 1-4 WAN 1-4 Wireless 1-4 Cayman 2E-H-W User’s Guide November 2000 line display 4-38 Local Area Network (LAN) 1-2 location, SNMP 4-39, 4-40 log 4-11, 5-3 log command 4-7...
Page 168 4-42 set trafficshape commands 4-42 set wireless commands (802.11) 4-43 set wireless commands (HomeRF) 4-43 setup.exe program 6-3 show bridge interfaces 4-10 show bridge table 4-10 show command B-7 show crash 4-10 Cayman 2E-H-W User’s Guide November 2000...
Page 169 SNMP 4-39, 4-40 system diagnostics 4-41 system location 3-35 system name 3-12, 3-13, 3-16, 4-41 system password 4-42 Cayman 2E-H-W User’s Guide November 2000 technical specifications A-1 Telnet 3-26, 4-1, 4-31, 4-32 telnet command 4-13 Telnet traffic 4-39...
Page 170 Index Cayman 2E-H-W User’s Guide November 2000...

Cayman Systems 2E-H-W User Manual

Using the Command Line Interface

Diagnostic Console

C How Your Cayman 2E-H-W Works

Glossary

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cayman Systems 2E-H-W

Summary of Contents for Cayman Systems 2E-H-W

Table of Contents
