Quadratec QuadraTop Installation Manual page 9

Step 10
FIG 55
Secure the Over Door Attachments
Locate the two plastic strips sewn to the sides of the top above each door (FIG55).
Starting with the front strips, slip the strips into the channel in the door surround above the door opening (FIGs 56 & 57).
Secure the strips on each side of the vehicle. When com plete each side should look like FIG 58.
Please see separate attached sheet for complete care and maintenance suggestions to prolong the life of
NOTICE
your MasterTop Fabric only replacement soft top.
FIG 59
Install the Tailgate Bar and Rear Window to the Body of the Jeep®
Slide the"C" shaped channel onto the tube sewn into the rear window with the round seal down. See FIG 59 for correct
alignment. Slide the tailgate bar all the way across the rear curtain. Open the rear tailgate. As shown in FIG 60, insert/
roll the tailgate bar into the mounts on each side of the tailgate with the vinyl side of the rear curtain facing
the rear of the vehicle. Once the Tailgate bar in secure, lower zippers on both sides of the rear curtain (FIG 61) and
then secure the rear zipper cover flap as shown in FIG 62.
Folding Back the Front Section of your Top
Your Skymaster Replacement top is designed to be used with your factory fold back "sunroof" feature if it is a part
of your original soft top hardware. To fold back your SkyMaster Soft Top: If driving, stop the vehicle and put in park.
FIG 56
FIG 60
FIG 63
FIG 57
FIG 61
FIG 58
FIG 62
