INSTALLATION AND CARE GUIDE
R
WOODBRIDGE
ELECTRONIC BIDET TOILET :LT610
Compliance with the following codes & standard:
®
( UPC )
• 2015 Uniform Plumbing Code
®
( IPC )
• 2018 International Plumbing Code
®
( IPC )
• 2018 International Residential Code
Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Pacific Time)
Or Email: help@woodbridgebath.com
20220628 REV. 2
www.woodbridgebath.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LT610 and is the answer not in the manual?

Questions and answers

Summary of Contents for Woodbridge LT610

  • Page 1 INSTALLATION AND CARE GUIDE WOODBRIDGE ELECTRONIC BIDET TOILET :LT610 Compliance with the following codes & standard: ® ( UPC ) • 2015 Uniform Plumbing Code ® ( IPC ) • 2018 International Plumbing Code ® ( IPC ) • 2018 International Residential Code Customer Service Phone: 562-229-0088.
  • Page 2: Table Of Contents

    Content Safety instructions Technical specification List of materials Technical drawing Parts identification Toilet installation Preparation Lid auto open/close Maintenance 1. Main unit care and maintenance 2. Spray nozzle maintenance and care 3. Filter maintenance Emergency troubleshooting 1. Power and water failure 2.
  • Page 3 IMPORTANT SAFEGUARDS When using electrical products, especially when children are present, basic safety precautions should always be followed, including the following: 1. The appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction.
  • Page 4: Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS CAUTION – Indicates that failure to follow the instruction may cause body injury or property damage. 1. Do not install or use the product in wet places as steam room etc. 2. It is recommended to use water-proof electrical outlet which should be installed in a place where is not easily to get wet.
  • Page 5: Technical Specification

    Technical Specification Rated voltage 110V-120V, 50/60Hz Rated power 1170-1210W Main Unit Water proof IPX4 Power cord length About 86" Flush volume 1.27Gpf(full flush 1.6G/half flush 1.1G) Flushing mode Siphonic jet Rough-in 12" Toilet Outlet outside diameter ≤3.9" Drainage method S-trap Water pressure range 0.08MPa - 0.8MPa Heating mode...
  • Page 6 Deodorization Deodorization method Diatom Deodorization Surface temperature 6-level adjustment Heating power Heated seat After 10 minutes of use, the seat temperature will Burn protection automatically drop slowly to a low level Seat sensor, Temperature sensor, Thermostat, Safety device Thermal fuse, Leakage protection plug Night light assembly Intelligent, Always on, Always off User ID setting...
  • Page 7: List Of Materials

    List of materials Main Unit Remote Controller Components Sealing Flange Installation Cardboard Installation Manual Thank you for choosing our products.Please read the instructions carefully before installation and keep it available for future maintenance or reference. Installation Manual Braided hose Mounting accessory kit www.woodbridgebath.com...
  • Page 8: Technical Drawing

    Technical drawing 43" 27 7/8" 20 3/4" 16 3/4" 16" 16 3/8" 1. The drawing is for reference only, and we reserve the right to modify the product appearance. 2. Product appearance is subject to change in kind. www.woodbridgebath.com...
  • Page 9: Parts Identification

    Parts identification Bumper Left side Knob Indicator light Seat Front washing Rear washing Ceramic toilet Dryer shield Rear washing Front washing Spray Power cord nozzle Manual flush button Deodorizer Right side Touch the sensing area with foot (optional) www.woodbridgebath.com...
  • Page 10: Toilet Installation

    Toilet installation 1. Cardboard cut out template installation 3. Mounting bracket installation Align cardboard with the centerline of Assemble the mounting bracket with bolts drain outlet. and then install them to the pre-installed Draw contour line according to cardboard. flange plate on the ground and lock tight with nuts.
  • Page 11 4. Ceramic toilet installtion 5. Screw installation Install a sealing flange into drain outlet; Put the screw through the fixing sleeve and then install it through the holes (on both sides Install ceramic toilet on the corresponding of the toilet ceramic) to the mounting bracket position.
  • Page 12: Preparation

    Preparation 1. Turn on the angle valve Check the threaded connection for leaks to ensure complete sealing. Turn the angle valve counterclockwise to the full open position. (Note: The angle valve opens with a large torque for the first time.) Angle valve 2.
  • Page 13: Lid Auto Open/Close

    Lid auto open/close Only for the product with auto lid opening/closing function. This function is turned off by default. For the first use, please turn on this function by remote control. 1. Approaching the toilet When user enters the sensing range, the seat lid opens automatically.
  • Page 14: Maintenance

    Maintenance Main unit care and maintenace Spray nozzle maintenance and care 1. Shut off power supply before doing 1. Nozzle self-cleaning maintenance. When no one is seated, turn the knob clockwise. The nozzle will automatically 2. Use only a soft, damp cloth to clean. Avoid stretch out to allow access for cleaning using harsh chemicals.
  • Page 15: Emergency Troubleshooting

    Emergency troubleshooting 1. No power Press and hold the manual flushing button to flush the toilet。 Manual flushing button 2. No water supply Put around 2Gal (8L) water into a barrel and flush the ceramic bowl. Note: Avoid water spilling from bowl.
  • Page 16: Failure Of Remote Control

    Failure of remote control Product unused for a period of time 1. Operate via knob on the main unit When the product is left unused for a long time, especially in cold weather, it is highly recommended to drain the water to prevent freezing.
  • Page 17: Description Of The Knob Function

    Description of the knob function 1.When seated, turn the knob clockwise to start rear washing function, and turn counterclockwise to start front washing function. Rear and front washing function will automatically enter into the drying function after completion. (Note: default water pressure, water temperature, air temperature, seat temperature, wand position are intermediate.) 2.
  • Page 18: Troubleshooting Guide

    Troubleshooting guide Problem Cause Solution Water supply hose is kinked Straighten the hose to remove the kink No water from Angle valve is off Turn on the angle valve nozzle A water failure occurred Restore the water supply Water supply hose is kinked Straighten the hose to remove the kink Poor water Angle valve is not fully turned on...
  • Page 19 www.woodbridgebath.com...
  • Page 20 Thank you for using WoodBridge products! Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Pacific Time) Or Email: help@woodbridgebath.com www.woodbridgebath.com...
