Summary of Contents for Woodbridge LT610
- Page 1 USER MANUAL LT610 WOODBRIDGE Remote Control Illustration Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Pacific Time) Or Email: help@woodbridgebath.com 20220526 REV. 1 www.woodbridgebath.com...
-
Page 2: Table Of Contents
Content Installation preparation 01. Remote control installation 02. Battery installation Usage instruction 01. Remote control instruction 02. Rear/Front cleaning operation 03. Drying/Dryer temperature 04. Water volume adjustment 05. Spray nozzle position adjustment 06. Energy saver 07. Water temperature adjustment 08. Seat temperature adjustment 09. -
Page 3: Installation Preparation
Installation Preparation Remote control installation Remote control hanger installation 1： 1.Drill a 6 mm diameter hole in the wall to a depth of about 35 mm. 2.Tear off the double-sided adhesive sticker on the back of the hanger. 3.Install the expansion pipe into the wall hole, and align it with the hanger hole. Attach the double-sided adhesive sticker on the back of the hanger to the wall,lock the screw, and tear off the double-sided adhesive sticker on the back of the patch and stick it on. -
Page 4: Remote Control Instruction
Installation Preparation Remote control instruction Drying/ Dryer temperature Rear washing/ Moving washing Front washing/ Moving washing Indicator light Nozzle moving forward Water reducing Water increasing Stop/Energy saver Nozzle moving backward Night light Water Seat temperature temperature Deodorizer Full flush Half flush Open /Close the seat Open / Close the lid... -
Page 5: Rear/Front Cleaning Operation
Usage Instruction Notice : · The body should touch the seat and the buzzer rings "CLICK", which means functions of front cleaning, rear cleaning and drying are in operation. · Please stay backward when sitting on the seat. So that the cleansing position can be easily aligned and there will be no splash. -
Page 6: Drying/Dryer Temperature
Usage Instruction DRY|DRYER TEMP (Only applicable to implement with drying function) ①Press the " " button, the indicator light will light up, showing the current air temperature range. It will stop drying automatically after a cycle or after the human body leaves the seat. ②In the process of drying, press the "... -
Page 7: Water Temperature Adjustment
Usage Instruction Water temperature adjustment Short press the " " button to adjust the water temperature. The indicator will show the water temperature level if it’s on. When the indicator is off, the water level is 0. Short press this button to adjust water temperature level from 0 to 5 in cycle. -
Page 8: Open/Close By Remote Controller
Usage Instruction Open/Close by remote controller (Only for toilet with this function) Short press " " button，open or close the lid. Short press " " button，open or close the seat. OPEN CLOSE THE LID Long press " " button to turn on/off auto lid open/close function. (This function is set to off by default and needs to be turn on by users if it’s needed.) OPEN CLOSE THE SEAT Deodorant set... -
Page 9: Other Operations
Other Operations Other operations User code · Radio frequency remote control ① Unplug to cut off the power supply of the toilet ② First press " " button, then press " " button, the indicator light will flash. ③ Plug in the toilet and press the “reset” button. ④... - Page 10 www.woodbridgebath.com...
- Page 11 www.woodbridgebath.com...
- Page 12 Thank you for using WoodBridge products! Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Pacific Time) Or Email: help@woodbridgebath.com www.woodbridgebath.com...
