INSTALLATION MANUAL BID 02
ELECTRONIC TOILET SEAT
● Thank you for choosing our products.Please read the instructions carefully before
installation and keep it available for future maintenance or reference.
● Our company reserves the right of final interpretation for this manual.
The manual is subject to change without notice.
Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Pacific Time)
WOODBRIDGE
Installation Manual
Or Email: help@woodbridgebath.com
www.woodbridgebath.com
R
2020413 REV. 3
Advertisement
Table of Contents
Related Manuals for Woodbridge BID 02
Summary of Contents for Woodbridge BID 02
- Page 1 INSTALLATION MANUAL BID 02 WOODBRIDGE ELECTRONIC TOILET SEAT Installation Manual ● Thank you for choosing our products.Please read the instructions carefully before installation and keep it available for future maintenance or reference. ● Our company reserves the right of final interpretation for this manual.
-
Page 2: Important Safeguards
WOODBRIDGE IMPORTANT SAFEGUARDS When using electrical products, especially when children are present, basic safety precautions shouldalways be followed, including the following: 1.The appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction. -
Page 3: Important Safety Instructions
WOODBRIDGE IMPORTANT SAFETY INSTRUCTIONS CAUTION – Indicates that failure to follow the instruction may cause body injury or property damage. 1. Do not install or use the product in wet places as steam room etc.This product must be connected to properly grounded power outlet socket. -
Page 4: Technical Specification
WOODBRIDGE TECHNICAL SPECIFICATION Technical Specification Rated voltage 110-120V，50/60Hz Rated power 960W Main Unit The minimum necessary pressure 0.08MPa (hydrostatic pressure), Water pressure the maximum water pressure 0.8MPa (hydrostatic pressure) range Power Cord length is about 1.2m 1400W(120V) Heating power Water... -
Page 5: Packaging List
WOODBRIDGE PACKAGING LIST Components Name Release button Leakage protection plug Infrared receiver Buffer Power cord Water supply pipe Nozzle baffle Drying Seat baffle Nozzle Rear cleaning Front cleaning The remote control Whole set of product www.woodbridgebath.com... - Page 6 WOODBRIDGE MAIN UNIT IDENTIFICATION Main Unit Knob Instructions (Knob Applies) Back Front 1. When people is seated, turn Rear Cleaning Knob forward to start rear Rear cleaning function; Rear cleaning → Drying→Stop drying automatically. Cleaning 2. During rear cleaning, turn the knob forward, the washing position moves Knob forward, otherwise, the washing position moves backward.
-
Page 7: Packing List
WOODBRIDGE Packing List Remote control rack Remote control 1.Remote control The remote control Expansion screws (2) 2.Remote control rack assembly 3.Expansion screws (2) Screws 1.Base plate Fixed piece 2.Screws (2) Base plate assembly Floor 3.Fixed piece (2) Expansion nut 4.Expansion nut (2) -
Page 8: Installation Instruction
WOODBRIDGE INSTALLATION INSTRUCTION Product Size and Installation Preparation Tool 130-190mm 403mm ＋ 380mm Phillips screwdriver Wrench Tape measure * Tips: Please confirm this seat fitting your current toilet. Installation of Main Unit * This product has been tested for water flow before leaving the factory. There may be a small amount of residual water dripping out when removing the product, which is not a malfunction. - Page 9 WOODBRIDGE Installation of Water inlet pipe and Tee joint Connect to Water supply pipe Current toilet water supply pipe Connect to main unit Connect to the Water Inlet pipe angle valve Tee Joint Angle Valve ① Connect Tee joint to angle valve; (The original Tee joint should be removed);...
-
Page 10: Preparation For Start-Up
WOODBRIDGE DAILY MAINTENANCE Preparation for Start-Up 1. Turn on the angle valve Check the tightness of the threaded connection to ensure that there is no water leakage. Turn the angle valve counterclockwise to adjust the opening to the maximum. (Tips: when the valve is opened for the first time, the angle valve handle has a large torque) Angle valve 2. -
Page 11: Daily Maintenance
Daily Maintenance Maintenance of Main Unit 1.Turn off the power during maintenance of this machine. 2. Wipe the dirty area with a soft cloth that is wrung out of water. 3. After wiping, please turn on the power again. Neutral cleaner Tips: Do not rinse the surface of the product directly with water during maintenance. - Page 12 WOODBRIDGE TROUBLESHOOTING GUIDE Self-cleaning Waterway Maintenance Current-limiting shaft Current-limiting nut Self-cleaning waterway maintenance： When the self-cleaning waterway is blocked, Note: there is no water coming out during self-cleaning Cut off power prior to discharging process. the water. 1. Turn off the angle valve.
-
Page 13: Troubleshooting Guide
WOODBRIDGE Troubleshooting Guide Problem Cause Solution Solve the problem of bending of Water inlet hose bent to cause water inlet hose blocking No Water from Inlet valve is off Turn on the inlet valve Nozzle Connect water supply and Water supply is cut off... - Page 14 WOODBRIDGE NOTES NOTES INSTALLER INFORMATION INSTALLER INFORMATION DATE OF INSTALL: DATE OF INSTALL: INSTALLER’S NAME: INSTALLER’S NAME: PLUMBER: PLUMBER: CONTRACTOR: CONTRACTOR: LICENSE #: LICENSE #: Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Pacific Time) Or Email: help@woodbridgebath.com...
