I/O & Power Interface
# Signal
24 Vin+
23 Vin-
22 Digital in 1+
21 Digital in 2-
20 Digital Input Common
19 (not connected)
18
17 EIA-232 Receive
16 EIA-232 Transmit
15 EIA-485 Common
14 EIA-485 Line A
13 EIA-485 Line B
See also...
• 3-1 "Technical Specification" (Power Supply Requirements)

EIA-232 Interface

The 9-pole DSUB, male connector on the Serial Server features a fully equipped EIA-232 interface. This
port can be used to connect to any equipment with an EIA-232 interface. The Serial Server is configured
as a DTE device.
The following signals are available:
# Signal
1 CD
2 Rx
3 Tx
4 DTR
5 GND
6 DSR
7 RTS
8 CTS
9 RI

Ethernet Interface

The Ethernet interface supports 10/100Mbps, using a standard RJ45 connector.
Comments
Voltage Range: 9... 32VAC/DC
(Ground connection)
-
-
(Not used)
This port can be used to connect to any equipment with an EIA-485 interface.
Comments
Carrier Detect
Receive
Transmit
DTE Ready
Signal ground
DCE Ready
Request To Send
Clear To Send
Ring Indicator
About the Anybus Serial Server 1-4
1 (male) 5
6 9
