- Page 1 Modbus RTU Master and Modbus TCP slave USER MANUAL Issue date: 08/2019 r1.1 ENGLISH...
- Page 2 HMS Industrial Networks reserves the right to modify its products in line with its policy of continuous product development. The information in this document shall therefore not be construed as a commitment on the part of HMS Industrial Networks and is subject to change without notice.
- Page 3 Router for the integration of Modbus RTU installations into Modbus TCP enabled monitoring and control systems. ORDER CODE LEGACY ORDER CODE INMBSRTR0320000 IBMBSRTR0320000 © HMS Industrial Networks S.L.U - All rights reserved https://www.intesis.com This information is subject to change without notice 3 / 17...
-
Page 4: Table Of Contents
3.2.6 Diagnostic ..........................14 Set-up procedure ..........................15 4 Electrical & Mechanical Features ......................16 5 Dimensions ............................17 © HMS Industrial Networks S.L.U - All rights reserved https://www.intesis.com This information is subject to change without notice 4 / 17... -
Page 5: Description
This document assumes that the user is familiar with Modbus technologies and their technical terms. Routing between Modbus RTU and Modbus TCP networks © HMS Industrial Networks S.L.U - All rights reserved https://www.intesis.com This information is subject to change without notice... -
Page 6: Functionality
Number of Modbus Number of Modbus slave Up to 32 full-load RTU devices slave devices devices supported by the device © HMS Industrial Networks S.L.U - All rights reserved https://www.intesis.com This information is subject to change without notice 6 / 17... -
Page 7: Connections
120 Ω. Ensure proper space for all connectors when mounted (see section 5). © HMS Industrial Networks S.L.U - All rights reserved https://www.intesis.com This information is subject to change without notice... -
Page 8: Powering The Device
User Manual). One method to connect to the PC can be used: • Ethernet: Using the Ethernet port of Intesis. © HMS Industrial Networks S.L.U - All rights reserved https://www.intesis.com This information is subject to change without notice... -
Page 9: Set-Up Process And Troubleshooting
Intesis and a Modbus RTU slave connected to its corresponding port as well. Connectors, connection cables, PC to use the configuration tool and other auxiliary material, if needed, are not supplied by HMS Industrial Networks S.L.U for this standard integration. Items supplied by HMS Networks for this integration are: •... -
Page 10: Connection
3.2.2 Connection To configure the Intesis connection parameters press on the Connection button in the menu bar. Figure 3.1 MAPS connection © HMS Industrial Networks S.L.U - All rights reserved https://www.intesis.com This information is subject to change without notice 10 / 17... -
Page 11: Configuration Tab
General (Gateway general parameters), Modbus slave (Modbus TCP slave interface configuration) and Modbus Router (Modbus TCP & RTU interfaces parameters). Figure 3.2 Intesis MAPS configuration tab © HMS Industrial Networks S.L.U - All rights reserved https://www.intesis.com This information is subject to change without notice... -
Page 12: Signals
Intesis MAPS user manual. Figure 3.3 Intesis MAPS Signals tab © HMS Industrial Networks S.L.U - All rights reserved https://www.intesis.com This information is subject to change without notice... -
Page 13: Sending The Configuration To Intesis
Figure 3.4 Intesis MAPS Receive/Send tab After any configuration change, do not forget to send the configuration file to the Intesis using button Send File. © HMS Industrial Networks S.L.U - All rights reserved https://www.intesis.com This information is subject to change without notice... -
Page 14: Diagnostic
Figure 3.5 Diagnostic More information about the Diagnostic section can be found in the Configuraion Tool manual. © HMS Industrial Networks S.L.U - All rights reserved https://www.intesis.com This information is subject to change without notice 14 / 17... -
Page 15: Set-Up Procedure
OK. In case there is no communication activity between Intesis and the Modbus devices, check that those are operative: check the baud rate, the communication cable used to connect all devices and any other communication parameter. © HMS Industrial Networks S.L.U - All rights reserved https://www.intesis.com This information is subject to change without notice... -
Page 16: Electrical & Mechanical Features
1500VDC isolation from other ports Operation 0°C to +60°C Temperature Operational 5 to 95%, no condensation Humidity IP20 (IEC60529) Protection © HMS Industrial Networks S.L.U - All rights reserved https://www.intesis.com This information is subject to change without notice 16 / 17... -
Page 17: Dimensions
Recommended available space for its installation into a cabinet (wall or DIN rail mounting), with space enough for external connections 70 mm (h) 100 mm (d) 60 mm (w) © HMS Industrial Networks S.L.U - All rights reserved https://www.intesis.com This information is subject to change without notice 17 / 17...
