Johnson Controls M4-XPM Installation Manual page 21

Table 13: Technical specifications
Communications bus
Processor
Memory
Input and output capabilities
Universal Input (UI) Resolution / Analog
Output (AO) Accuracy
Terminations
Mounting
Housing
Dimensions (height x width x depth)
Weight
Compliance
The performance specifications are nominal and conform to acceptable industry standard. For application at conditions beyond
these specifications, consult the local Johnson Controls office. Johnson Controls shall not be liable for damages resulting from
misapplication or misuse of its products.
RS-485
3-wire FC Bus between the supervisory controller and expansion modules
4-wire SA Bus between equipment controller, network sensors and other sensor/actuator
devices, includes a lead to source 15 VDC supply power (from equipment controller) to
bus devices.
RX64M Renesas 32-Bit microcontroller
®
16 MB flash memory and 8 MB SDRAM
Universal Inputs: Defined as 0–10 VDC, 4–20 mA, 0–600k ohms, or Binary Dry Contact
Binary Inputs: Defined as Dry Contact Maintained or Pulse Counter/Accumulator Mode
Configurable Outputs: Defined as 0-10 VDC or 24 VAC @500mA Triac BO
Analog Outputs: Defined as 0–10 VDC or 4–20 mA
Binary Outputs: Defined as 24 @500mA VAC Triac (external power source only)
Input: 24-bit Analog to Digital converter
Output: +/- 200 mV accuracy in 0–10 VDC applications
Input/Output: Pluggable Screw Terminal Blocks
SA/FC Bus and Supply Power: 4-Wire and 2-Wire Pluggable Screw Terminal Blocks
SA/FC Bus Port: RJ-12 6-Pin Modular Jack
Horizontal on single 35 mm DIN rail mount (recommended), or screw mount on flat
surface with three integral mounting clips on controller
Enclosure material: ABS and polycarbonate UL94 5VB; Self-extinguishing
Protection Class: IP20 (IEC529)
XPM09090-0: 150 mm x 190 mm x 44.5 mm (5-7/8 in. x 7-1/2 in. x 1-3/4 in.) including
terminals and mounting clips
XPM04060-0 and XPM18000-0: 150 mm x 152 mm x 44.5 mm (5-7/8 in. x 6 in. x 1-3/4 in.)
including terminals and mounting clips
Note: Mounting space requires an additional 50 mm (2 in.) space on top,
bottom, and front face of controller for easy cover removal, ventilation, and wire
terminations.
XPM09090-0: 0.5 kg (1.1 lb)
XPM04060-0 and XPM18000-0: 0.29 kg (0.64 lb)
United States: UL Listed, File E107041, CCN PAZX, UL 916, Energy Management
Equipment
FCC Compliant to CFR47, Part 15, Subpart B, Class A
Canada: UL Listed, File E107041, CCN PAZX7 CAN/CSA C22.2 No. 205, Signal Equipment
Industry Canada Compliant, ICES-003
Europe: Johnson Controls declares that this product is in compliance with the essential
requirements and other relevant provisions of the EMC Directive and RoHS Directive.
Australia and New Zealand: RCM Mark, Australia/NZ Emissions Compliant
BACnet International: BACnet Testing Laboratories™ (BTL) Protocol Revision 18 Listed
and Certified BACnet Smart Actuator (B-SA), based on ANSI/ASHRAE 135-2020
United Kingdom: Johnson Controls declares that this product is in compliance with
Electromagnetic Compatibility Regulations, The Electrical Equipment (Safety) Regulations,
and Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic
Equipment Regulations.
M4-XPM Expansion Modules Installation Guide 21
