Table 6: Termination details
Type of field
Type of Input/
device
Output
Temperature
UI
Sensor
Voltage Input -
UI
External Source
Voltage Input -
UI
Internal Source
Voltage Input
UI
(Self-Powered)
Current Input -
UI
External Source
(Isolated)
Termination diagrams
M4-XPM Expansion Modules Installation Guide
