Table 6: Termination details
Type of field
Type of Input/
device
Output
Current Input -
UI
Internal Source (2-
wire)
Current Input -
UI
Internal Source (3
wire)
Current Input -
UI
External Source (in
Loop)
Feedback from
UI
EPP-1000
Dry Contact
UI or BI
(Binary Input)
12
M4-XPM Expansion Modules Installation Guide
