Storing and Recalling Presets
Use the MTX3-16-M
connection scenarios. A green dot indicates that the preset is storing a connection scenario.
To store the current input/output connection scenario as a preset:
1. Go to the Routing Settings page and set the desired connection scenario.
2. Under PRESETS, click Save to save the connection scenario to a preset (1 to 60).
The current video and audio input/output configuration is stored.
To recall a stored preset:
•
Under PRESETS, click Load next to the desired preset number (1 to 60) that you would
like to recall.
The preset is recalled and the input/output connection scenario changes to the selected
preset.
Viewing / Configuring Port Settings
Use the MTX3-16-M
matrix card (input or output).
The Port tab of the Settings page also shows the port information/configuration panel
(see Configuring Input / Output Ports
MTX3-16-M – Managing MTX3-16-M from the Embedded Web UI
web-UI to store and recall up to 60 different video and audio input/output
Figure 35: Routing Settings Page – Presets
Routing Settings web-UI page to view and configure settings for each
on page 43).
