complements
Section:
H.A. TABLES
Description:
COMPLEMENTS NAVIGATE TABLE - ELECTRIC
INSTALL STRUT COVER
F
L11
L11
STEP 10: Install worksurface as shown above. Secure Frame Assembly, Switch and Control
Box. then install Control Box Cover onto the Cross Beam.
Installation Guides
F
INSTALL POWER BOX (OPTIONAL)
NOTE: Position of the External
Power Box is for reference only. It can
be shifted as per user's preference.
N6
STEP 11: Attach and secure external Power Box as shown.
Date:
May 2019
COM_150b
N5
Page No:
9 of 10
