EZ500 Diagnosis System
Declaration
1. This manual is designed for the usage of EZ500, applying to EZ500 automotive diagnosis platform.
No part of this manual can be reproduced, stored in a retrieval system or transmitted, in any form or
by any means (electronic, mechanical, photocopying, recording, or otherwise), without the prior
written permission of Xtool.
2. Use the device only as described in this manual. The user will be responsible solely for the
after-effects of violating the laws and regulations caused by using the product or its data information;
in this case Xtool will not bear any legal responsibility.
3. Xtool shall not be liable for any incidental or consequential damages or for any economic
consequential damages arising from the accidents of individual users and the third parties, misuse or
abuse of the device, unauthorized change or repair of the device, or the failure made by the user not
to use the product according to the manual.
4. All information, specifications and illustrations in this manual are based on the latest configurations
and functions available at the time of printing. Xtool reserves the right to make changes at any time
without notice.
5.
is the registered trademark of SHENZHEN XTOOLTECH CO.,LTD.
6.In countries that the trademarks, service marks, domain names, logos and the name of the company
are not registered, Xtool claims that it still reserves the ownership of the unregistered trademarks,
service marks, domain names, logos and the company name. All other marks for the other products
and the company's name mentioned in the manual still belong to the original registered company.
You may not use the trademarks, service marks, domain names, logos and company name of Xtool or
other companies mentioned without written permission from the trademark holder.
7. Please visit www.xtooltech.com for more information on the EZ500.
8. Xtool reserves the right for the final interpretation of this manual content.
Xtool EZ500 User Manual Instructions
Please read this user manual carefully before using the scanner.
When reading the manual, please pay special attention to the words "Note", "Caution" or "Warning",
read them carefully for appropriate operation.
Xtool EZ500 Diagnosis System Main Unit Maintenance
Avoid shaking or dismantling the unit as it may damage the internal components.
Do not use hard or sharp objects to touch the LCD screen; do not use excessive force; do not expose
the screen to strong sunlight for a long period.
Caution: keep it away from water, moisture, high temperature or very low temperature.
If necessary, calibrate the screen before testing to ensure the accuracy of LCD performance.
Keep the main unit away from strong magnetic fields.
1

Advertisement

Table of Contents
loading

Summary of Contents for Xtool EZ500

  • Page 1 4. All information, specifications and illustrations in this manual are based on the latest configurations and functions available at the time of printing. Xtool reserves the right to make changes at any time without notice.
  • Page 2 Manufacturer of Power Adapter: Shenzhen Mingxin Power Technologies Co.,Ltd. Parameters of Power adapter: Input: AC 100-240V 50-60Hz 1A; Output: DC 12V 3A. Declaration of Conformity Hereby, XTOOLTECH declares that this EZ500 is in compliance with the essential requirements and other relevant provisions of directive 1995/5/EC.
  • Page 3: Table Of Contents

    2.2. Side View of EZ500 Tablet....................5 3. EZ500 Technical Parameters....................... 5 CHAPTER Ⅱ How to Use EZ500 ......................6 1. EZ500 Activation........................6 2. EZ500 Main Interface and Functional Buttons Descriptions............7 2.1. Main Interface........................7 2.2. Sub-menu and Functional Buttons ..................7 2.3. Toolbar Functional Buttons....................8 3.
  • Page 4: Chapter Ⅰ About Ez500

    EZ500 Diagnosis System CHAPTER Ⅰ About EZ500 1. Appearance 1.1. Front View 1.2. Back View...
  • Page 5: Layout Of Ez500 Tablet

    EZ500 Diagnosis System 2. Layout of EZ500 Tablet 2.1. Top View of EZ500 Tablet ① ② ③ ④ Charging port: Battery charging DB15 Port: Supports wired connection with car by the cable USB Type C Port: Compatible with HDMI TV port, and support for quick charging. (This port shall only be connected to a USB interface of version USB3.1 )
  • Page 6: Chapter Ⅱ How To Use Ez500

    CHAPTER Ⅱ How to Use the EZ500 1. EZ500 Activation 1.1. Please activate EZ500 before you use it to test vehicles. 1.2. Input activation code (on the manual cover), product serial number (each device will have a serial number and activation code), nickname (workshop’s name or user’s nickname), login account (can be your email address or cell phone number) and password, the system will then save it.
  • Page 7: Ez500 Main Interface And Functional Buttons Descriptions

    EZ500 Diagnosis System 2. EZ500 Main Interface and Functional Buttons Descriptions 2.1. Main Interface Tap on EZ500 application icon, the main interface and sub-menus will be shown as below. 2.2. Sub-menus and Function Buttons Function Buttons Descriptions Opens the EZ500 diagnostic application. It can read diagnostic information, view live data, perform actuation tests and special functions etc.
  • Page 8: Toolbar Functional Buttons

    3. Vehicle Connection Diagnosis 3.1. Vehicle Connection Test a. Connect scanner and vehicle with cable in following order: :①②③ b. Switch on the ignition and turn on EZ500 tablet, then tap on EZ500 application icon to test vehicles. (Shown as follows) EZ500 Mainframe...
  • Page 9: Precautions Before Use

    (such as headlights, air-conditioner, etc.), put accelerator pedal in released position, etc. 3.2.4. If users can not find the tested vehicle model or electronic control system in the EZ500 test menu, they may need to update the software or consult Xtool technical service department.
  • Page 10: Test Functions

    EZ500 Diagnosis System 4.2. Test Functions 4.2.1. Using VW as an example, select Diagnosis, then select EUROPE. Choose the VW logo. If the logo is not showing on the screen, please swipe up or down to display it. PLEASE NOTE: Different vehicles have different menus and systems.
  • Page 11 Descriptions Returns to previous interface Print test data Click to record the data, click again to send your feedback to XTOOL service center After clicking the data record button the second time the data feedback page will appear as shown below, showing diagnostic software version, vehicle being tested, and the steps performed in the diagnostic process.
  • Page 12: Read Ecu

    EZ500 Diagnosis System 4.3. Read ECU This function is used to read ECU version information, which is the equivalent of “System Identification” or “System Information” in some electronic control systems. This will allow you to read ECU related software and hardware versions, models and production date of diesel engine, part number, etc.
  • Page 13: Clear Dtcs

    EZ500 Diagnosis System such as a mechanical system fault. It is also possible that the signal of a system sensor may be incorrect but still within the ECUs stored limits, this can be verified in Live Data. 4.5. Clear DTCs 4.5.1.
  • Page 14 EZ500 Diagnosis System Tip: Live Data is important function that can be used to help technicians further diagnose a problem. This function requires technicians to be familiar with sensor data of each system, control signals and control modes. Tip: Save known good live data readings for comparison.
  • Page 15 EZ500 Diagnosis System...
  • Page 16: Special Functions

    EZ500 Diagnosis System 4.7. Special Functions Different vehicle makes and models will have different special functions. 4.8. Actuation/Active Components Test Test Conditions: Ignition on engine off. If the engine is started or an engine rotation speed signal is received, component actuation will be interrupted.
  • Page 17: Settings

    EZ500 Diagnosis System Tip: Actuating Components Test performs function tests for system components. When performing this function, the diagnostic tool will simulate the ECU signal to enable the user to judge whether the actuating components or circuits are working correctly.
  • Page 18: Xcloud

    Xtool users in our forum, but can also access various online databases of maintenance and diagnostic skills and vehicle maintenance plans.
  • Page 19: Report

    EZ500 Diagnosis System 8. Report Report is used for viewing and printing the saved files, such as Live Data, Trouble Codes or pictures generated in the process of diagnosis, users also can view a record of which cars have been previously tested.
  • Page 20 EZ500 Diagnosis System 8.1.2 Click PDF icon to generate PDF when you want to save the trouble code report 8.2. Pictures: Pictures are all the screen capture files saved in the diagnosis process. 8.3. Data Replay: With Data Playback you can play back recorded Live Data & freeze frame data.
  • Page 21: Remote

    If users encounter problems and are not able to solve them, they can open this application and ask for remote assistance. How to get remote assistance from Xtool Technical Assistance Center: Open EZ500 Click Remote and open the TeamViewer interface. Generate and display device ID.
  • Page 22: Chapter Ⅲ Location Of Diagnostic Link Connectors On Different Vehicle Models

    EZ500 Diagnosis System CHAPTER Ⅲ Examples of Diagnostic Link Connector Locations. 1. Diagnostic Link Connectors Locations of Various Vehicle Models *AUDI A6: the OBD plug is on the lower left side of the dashboard, use SMART OBDII-16 connector. *VW Bollywood 1.8: the OBD plug is below the console, use SMART OBDII-16 connector.
  • Page 23 EZ500 Diagnosis System *Benz C180: the OBD plug is on the left hand side of the engine bay, use Benz-38 connector. *Benz 300SEL 140 chassis: the OBD plug is on the left hand side of the engine bay, use Benz-38 connector.
  • Page 24 EZ500 Diagnosis System *VW POLO: the OBD plug is below the dashboard, use SMART OBDII-16 connector. *BMW 735I: the OBD plug is in the right hands side of the engine bay, use BMW-20 connector. *VW Passat B5: the OBD plug is behind the gearlever and beside the parking brake lever. Lift the cover...
  • Page 25: Location Diagram Of Vehicle Diagnostic Link Connectors

    EZ500 Diagnosis System 2. Location Diagram of Vehicle Diagnostic Link Connectors Location diagram of pick-up truck diagnostic link connectors: Location diagram of utility vehicles diagnostic link connectors: Link diagram of small car diagnostic link connectors: NOTE: Each vehicle manufacturer may use additional pins to diagnose a variety of systems. Not every manufacturer uses the same standard.
  • Page 26 EZ500 Diagnosis System Pin Definition (Reference material) Various pin definitions as follows: 1. Manufacturer definition 2. SAE J1850 bus positive 3. Manufacturer definition 4. Bodywork site 5. Signal site 6. ISO 15765-4 defined CAN high 7. ISO9141 and ISO14230 defined K line 8.
