- Page 1 W W W . N I T R O S C A N T O O L . C O M Nitro diagnostic system QUICK START GUIDE Nitro LT Nitro XT Nitro GT...
- Page 3 NITRO SCAN TOOL Declaration 1. This manual is designed for the use of Nitro scan tools. No part of this manual can be reproduced, stored in a retrieval system or transmitted, in any form or by any means (electronic, mechanical, photocopying, recording, or otherwise), without the prior written permission of XToolUSA ®...
-
Page 4: Front View
NITRO SCAN TOOL FRONT VIEW BACK VIEW Camera Speaker Serial Number and ID... -
Page 5: Top View
NITRO SCAN TOOL TOP VIEW USB3.0 interface: Wired data transmission Mini HDMI interface: Audio and video transfer DB15 interface: Extended reservation port DC charging port: Device Charging Power Button: Power on / off BOTTOM VIEW Charger Interface... - Page 6 NITRO SCAN TOOL Nitro LT Technical Information Operating System: Android 5.1.1 Processor: Quad core processor 1.8GHz Memory: 2GB RAM, 32GB ROM Display / touch screen: 1024*768 resolution, 8-inch LED touch screen Camera: 8 megapixels, with flash and autofocus. Sensor: accelerometer Audio input / output: microphone/speaker.
-
Page 7: Functional Buttons
NITRO SCAN TOOL NITRO SCAN TOOL Functional Buttons Functional Descriptions Diagnosis - Read vehicle diagnostic information, view and record live data, read and clear codes Pre-Scan - Generate Pre-Scan report continued on next page... - Page 8 NITRO SCAN TOOL continued from previous page... Functional Buttons Functional Descriptions Post Scan - Generate Post Scan Report Report Manager One-Click Update - Upgrade software Remote Control - XToolUSA support center Accessories - Flashlight and Demo Settings - Change machine settings for language and units Internet - Web Browser...
- Page 9 NITRO SCAN TOOL continued from previous page... Functional Buttons Functional Descriptions Return to the previous screen Decrease the volume Increase the volume Home button Page History Screenshot Bluetooth, turns blue when connected Click to record data...
-
Page 10: Quick Start
NITRO SCAN TOOL Quick Start Note: You must complete these steps to update and begin using the Nitro. Charge the Machine Connect the power supply and charge the machine until the battery is fully charged. WIFI Press the settings button and then select WIFI networks. Enter your wireless info and password. You are now connected to the internet. - Page 11 NITRO SCAN TOOL Connection LT The Nitro LT machine is connected to the vehicle through the OBDII main cable to the DLC as shown in this diagram. Nitro LT Tablet OBD Cable Vehicle OBDII adapter (use correct adapter for OBD1 vehicles) Connection XT and GT The Nitro XT and GT connect to the 16 pin DLC OBDII port through a Bluetooth connection.
-
Page 12: Remote Control
NITRO SCAN TOOL Remote Control If the scan tool user has encountered problems during the repair process, you can open this application for remote assistance and accept support from the XtoolUSA Tech-Support Center. This system can also be used by other Nitro users to help the requestor with diagnostics. -
Page 13: Warranty
NITRO SCAN TOOL Warranty LIMITED MANUFACTURER’S WARRANTY XtoolUSA warrants the Nitro Scan Tools™ in compliance with this certificate, in effect for 24 months from the date of ® purchase. In order to redeem the benefits provided to you by this warranty, this documentation must be provided in tandem with a verifiable proof of purchase, as issued by an authorized Nitro Scan Tool™... - Page 14 NITRO SCAN TOOL continued from previous page... How to Obtain Service and Support You may obtain service by accessing our website, www.nitroscantool.com/support or by calling us at (855) 562-5522 ext. 4005. Regular business hours are Monday through Friday 8am to 5pm Pacific Standard Time. To receive service or support, you agree to comply with each of the terms listed below: You will provide a copy of this warranty and a copy of your purchase, exchange and service receipts, if requested (ii)
- Page 16 Contact Be sure to visit our web page at www.nitroscantool.com for video, tech tips and other great helpful information on using your new tool. Telephone tech service is available for Nitro users with valid up to date subscriptions at 888-988-6865. This service is free if your tool is up to date.
