Teknion INTERPRET WORK TABLE Installation Manuals

interpret
Installation Guides
Section: TABLES
Description: BEGINNING WORK TABLE AND FINISH WORK TABLE - CURVED LEG
Beginning Work Table (WWTWB)
AC
AK1
AA1
Beginning Table - Curve Leg with
Glass infill shown.
Part and Product Identification
AI
AD
AH
AF1
AB3
AB1
AB2
Date: Jan 2018
INT_504b
AA1 -Curve Leg with
AF1 -Transverse Beam
Glass Infill
(N02-2349) x1
or Curve Leg with
AF2 -5/16-18x2.5 Soc
Wood Infill
(N02-2365) x1
or Curve Leg
AF3 -5/16-18 Hex
Open
(N02-2363) x1
AA2 -Curve Leg
Add-on Puck
(A18-0242) x8
AG -1/4-20 x 3 -1/2
AB1 -Mid Gable
(N02-2053) x1
AB2 -Leveler Cover
(A23-3670) x2
AH -Front Standoff
AB3 -End Cap
(B02-0389) x2
AC -Centre Spacer
(A16-1652) x1
AI -Flush Plate
AD -Mid Gable
Center Spacer
(A16-1653) x1
AJ -#10 x .875" LG.
AE -1/4-20x5/8
Mach. Screw
(E01-0098) x4
AK1 - Worksurface for Beginning
Table with Cut-out
(C05-7490) x 1
or
AK2 - Worksurface for Beginning
Table without Cut-out
(C05-7356) x 1
or
AK3 - Worksurface for Beginning
Table with CALA Cut-out
(C07-2519) x 1
Page No: 1 of 14
Rev. No: 1
Sub-Assembly
(N02-1935) x2
Head Cap Screw
(E01-0756) x16
Nut 1/2 A/F
.265 Thick
(E01-0755) x16
Flat Hd, Mac Sc.
(E01-0771) x4
(B02-0381)
widths 48"-72" x2
widths 72"-96" x4
(A15-6948) x 1
Quad Pan Screw
(E07-0077) x4
