Section: STORAGE
Description: PEDESTAL - SUSPENDED
PEDESTAL - SUSPENDED (WWGH)
NOTE: Ensure product is leveled
and if Front/Door alignment is
needed, perform the necessary
adjustment for the Fronts/Doors
insuring equal gap.
For Double Sided Frame WWSDC, WWSDB and WWSDF
≤ 72" wide, ONLY one WWGH
48" deep and
Suspended Pedestal can be installed per side.
For Single Sided Bench, WWEDA Data Tray needs to
be 15" shorter than width of Worksurface to provide
clearance for Pedestal.
NOTE: Adjust Front/Door by
Releasing the front mounting
screws, adjust front and tighten the
screws or use the hinge adjustment.
NOTE: Suspended Pedestal -
Box/File with Metal Front
shown as an example.
Part B to G will be shipped
pre-assembled.
A1 - 5/16-18x3.0 Length,
A2 - 5/16-18 Hex Nut,
A3 - Worksurface Spacer
A4
A4 - Suspending Bracket
A7
B
A5 - 1/4-20x .625 PAN
A6 - 1/4-20 UNC. Nut
A7 - Supporting Bracket
A8 - 1/4-20x3/8" MACH
F
A9 - Bumper .375 DIA
A10 - Suspended Pedestal
A11 - 1/4-20 x 1 1/2
Date:
INT_105a
Part and Product Identification
B - Suspended Pedestal
Hex Cap Screws
Grade2
(E01-0789) x4
1/2 A/F, .265 Thick
(E01-0755) x4
Block
(A25-0368) x2 C - Pedestal Double
(A16-1678) x1
D - Pencil/Small Box
Head QUAD Screw
(E01-0732) x4
Hex Keps Zinc
(E03-0059) x4
E - File Drawer,
(A16-1679) x1
Screw, QUAD, PAN
(E01-0014) x2
F - Metal Front, with
x .125 Height
Clear (BS-34)
(E08-0091) x2
Ganging Bracket
(A16-2026) x1
G - Pencil Tray
Thumb Screw,
Type B, Zinc
(E01-0852) x1
For Customer Support please contact
product.support@teknion.com
Feb 2022 Page No: 1 of 12
Rev. No: 2
Case Weldment
(N01-3100\16\18) x1
Lock Bar Kit
(N01-2244\03) x1
Drawer
Sub-Assembly
(N01-2240\18) x1
Sub-Assembly
(N01-2242\18) x1
Interpret Handle
(N01-3119\4_800) x1
(N01-3119\12_800) x1
or
Wood Front, with
Interpret Handle
(N01-3122SF) x1
(D04-0049) x1
