MT64DSU Owner's Manual
Elastic Store Enabled
Elastic Store Disabled
(Factory Default Setting
Switch #13
This switch must be in the DOWN position.
Switch #14
Dedicated/Switched Line Operation
(Asynchronous/Synchronous Mode)
The MultiDSU64K works over either Dedicated or Switched lines.
Note you must have this switch positioned in Switched Line mode
(UP) in order to issue AT Commands.
Switched Line
Dedicated Line
(Factory Default Setting
Switch #15
DTR Forcing
(Asynchronous/Synchronous)
It is advisable to force DTR in order for the terminal to communicate
properly with the DSU in Command mode.
DTR Controlled by DTE
DTR forced On
(Factory Default Setting
Switch #16
This switch is not used (reserved for future use).
20
= Switch #12 UP
= Switch #12 DOWN
= DOWN)
= Switch #14 UP
= Switch #14 DOWN
= DOWN)
= Switch #15 UP
= Switch #15 DOWN
= DN)
