Step 2 for Side B – Packet Filters
1.
Go to the Packet Filters screen to setup the other network across the VPN tunnel with the
rights to access across the tunnel
2.
Click on From (Host/Networks) and select the network you are allowing (you should already
have the LAN Any Any Accept listed).
3.
If you are not restricting the type of service, select Any for the To (Host/Network).
4.
Click the Add button to add the Packet Filter rule.
Important Note: Do not check the Status box. When adding a user-defined rule, leave the
Status box unchecked.
Step 3 for Side B – VPN Setup
1.
Go to the VPN > IPSec screen.
2.
Click the VPN Status check box to enable IPSec. Then click the Save button.
3.
Select Add an IKE Connection by clicking the corresponding Add button.
Multi-Tech Systems, Inc. RF820/830 IPSec VPN Setup Examples – A Reference Guide
Chapter 1 – Non-NAT Setup Examples
15
