4100/4120 INSTALLATION MANUAL

INSTALLATION CHECKLIST FOR SIMPLEX TECHNICAL REPRESENTATIVE

Step Procedure
1. Use the Packing List in the "Layout" pages to verify delivery/availability of all required
system hardware. This includes the printed circuit boards.
2. Unlock, then open the panel door. Remove the retainer by removing the top and
bottom screws, then squeeze and pull the two black plastic tabs located on the upper
part of the retainer. Lift the retainer from the back box.
3. Visually inspect the 4100 system. Verify that all wiring is connected to the panel, to
include the unified ground.
4. Use a volt/ohmmeter to check system wiring. This includes all wiring to the panel,
local and remote annunciators, etc. Check the AC power input to the power supply.
Repair required circuits prior to powering up the system.
5. Check jumpers, switches, capacitors and resistors on all system printed circuit
boards. Match the address label on the motherboard to the address label on the
daughter board, then install each daughter board.
6. Install all wiring harnesses and cables (except battery). This includes auxiliary relay
and signal cables.
7. Apply power to the system.
• If the system is trouble-free, perform "System Test Procedures".
• If the system displays abnormal conditions, perform troubleshooting procedures.
Document No: 4100-M002
24
Page
16
16
18
20
28
40
41
A1
Issue 1.0
