4100/4120 INSTALLATION MANUAL
Circuit Type
Style B (formerly Class B) Initiating Device (Zone) Circuit
From zone + to zone – (each zone)
From zone + to ground
From zone – to ground
Style D (formerly Class A) Initiating Device (Zone) Circuit
From zone + to zone – (each zone)
From zone + to ground
From zone – to ground
From zone + OUT to + IN
From zone – OUT to – IN
Style Y (formerly Class B) Notification Appliance Circuit (each signal circuit)
From + to ground
From – to ground
Resistance across circuit
In one direction
In opposite direction
Style Z (formerly Class A) Notification Appliance Circuit (each signal circuit)
From + to ground
From – to ground
From + OUT to + IN
From – OUT to – IN
Resistance across circuit
In one direction
In opposite direction
Shielding
Shield to ground
Shield to –
Shield to +
®
MAPNET II Loops (ZAMs and IAMs)
From MAPNET II
From MAPNET II
7. Check and terminate all remaining circuits (AC power, AUX, FB, City, MAPNET II
8.

Dress the panel wiring.

• Use the tie wraps in the System Hardware envelope to neatly dress the panel wiring.
9.

Install the option bay door.

10. Call your local Simplex Branch Office (listed in the Yellow Pages) to install the printed circuit boards
and test the system.
ONLY SIMPLEX REPRESENTATIVES ARE AUTHORISED TO APPLY
Document No: 4100-M002

Acceptable Zone and Signal Circuit Meter Readings

®
+ to ground
®
– to ground
AC OR BATTERY POWER TO THE 4100+ SYSTEM.
TABLE 2
6
Meter Reading
3.3K ohms
Infinity
Infinity
Infinity
Infinity
Infinity
Less than 50 ohms
Less than 50 ohms
Infinity
Infinity
10K ohms
Less than 200 ohms
Infinity
Infinity
Less than 50 ohms
Less than 50 ohms
Infinity
Less than 200 ohms
Infinity
Infinity
Infinity
Infinity
Infinity
®

, etc.).

Issue 1.0
