4100/4120 INSTALLATION MANUAL
3.3

Custom Label

The custom label identifies a location within the building or area, and contains additional information
concerning each circuit. Also included with the custom label is the corresponding zone name. This ties the
custom label to a zone name and allows the installer to identify where field wires are terminated, according
to zone name.
Examples:
3.4

Point Type

This is the type of device (indicating appliance, initiating device, relays, etc.) connected to each circuit.
Each device type is abbreviated. An operational description may also be included in the abbreviation.
Example:
The installer should use the System Point Summary when marking wires to the 4100 panel.
markings should include zones (ZNx+, ZNx--), signals (SIGx), etc., for each circuit within the system.
Marking each wire in this matter will facilitate termination and checking of the wiring in the 4100 panel.
NOTE: The SYSTEM POINT SUMMARY Report is found within the computer printout portion of the Factory
Documentation.
Document No: 4100-M002
_____________________________________________________________
6TH FLOOR NORTH WING EXHAUST FANS
1ST FLOOR SOUTH WING VISUALS
3RD FLOOR EAST WING STROBES
____________________________________________
AHUM (Air Handling Unit Monitor)
PRI (Primary Elevator Capture)___
FB25
SIGNAL 2
SIGNAL 40 _
9
These
Issue 1.0
