4100/4120 INSTALLATION MANUAL
NOTE: Systems are shipped from the factory with 3.3K OHM resistors. Use 3.3K OHM resistors for contact monitors
and 20 OHM resistors for RELAY or LED/lamp outputs.
Document No: 4100-M002

24 Point Graphic I/O Card Pluggable Resistors

PLUGGABLE RESISTOR SETTINGS
DRIVE # RESISTOR #
1 20
2 21
3 22
4 23
5 24
6 25
7 26
8 27
9 28
10 29
11 30
12 31
13 32
14 33
15 34
16 35
17 36
18 37
19 38
20 39
21 40
22 41
23 42
24 43
TABLE 5
(632-789)
INPUT
3.3K .5W
3.3K .5W
3.3K .5W
3.3K .5W
3.3K .5W
3.3K .5W
3.3K .5W
3.3K .5W
3.3K .5W
3.3K .5W
3.3K .5W
3.3K .5W
3.3K .5W
3.3K .5W
3.3K .5W
3.3K .5W
3.3K .5W
3.3K .5W
3.3K .5W
3.3K .5W
3.3K .5W
3.3K .5W
3.3K .5W
3.3K .5W
For Input Contact Monitors
28
OUTPUT
20 OHM 1W
20 OHM 1W
20 OHM 1W
20 OHM 1W
20 OHM 1W
20 OHM 1W
20 OHM 1W
20 OHM 1W
20 OHM 1W
20 OHM 1W
20 OHM 1W
20 OHM 1W
20 OHM 1W
20 OHM 1W
20 OHM 1W
20 OHM 1W
20 OHM 1W
20 OHM 1W
20 OHM 1W
20 OHM 1W
20 OHM 1W
20 OHM 1W
20 OHM 1W
20 OHM 1W
For Relays LED/Lamps
Issue 1.0
