8 Microphone (2) Work at a natural distance; disabled when an external
9 Fingerprint
reader
10 Ctrl+Alt+Del
(SAS - Secure
Attention
Sequence)
11 Ambient light
sensor
12 Speaker
13 Ethernet port
14 Docking port
15 Battery
16 Pen tether
17 Power indicator
light
18 Battery
indicator light
19 Hard drive
indicator light
20 Wireless
indicator light
21 Escape button
22 Function button Press this button then another to activate secondary
23 Five-way
directional
control button
Motion Computing LE-Series and LS-Series Tablet PCs User Guide 15
microphone is plugged in.
Swipe-type sensor for scanning fingerprints; used for
password management and security; also serves as a
vertical scrolling device in active application window
Performs the Ctrl+Alt+Del function; opens the Windows
Security window for additional operator action
Measures the background light and automatically
balances display brightness
Integrated speaker that is muted when you connect a
headset or external speakers
Standard 10/100 Ethernet LAN (RJ-45) connector that
can be used to connect to a network, cable modem, or
xDSL; it contains two status indicator lights.
Connects the LS-Series Tablet PC with the Motion
MobileDock for the LS series (not pictured in the
illustration) and provides the required signal connections
when the Tablet PC is docked. Refer to the Installation
Guide provided with the MobileDock for the LS-Series for
more information. Caution: Do not use the Motion LS-
Series Tablet PC with the Motion FlexDock for the LE-
Series.
The removable battery is mounted and latched at the top
of the LS-Series Tablet PC.
Attachment point for the digital pen tether
Displays power status; lights blue when power is on,
blinks blue when in stand by
Displays battery status; lights amber when battery is
charging, lights blue when fully charged
Displays hard disk drive (HDD) activity - blinks blue
Displays wireless 802.11 and Bluetooth activity; blinks
white for 802.11, blue for Bluetooth
• Primary function: Escape
• Secondary function: Alt+Tab
button functions
• Primary functions: Scrolls Up/Down/Right/Left + Enter
• Secondary functions: Left arrow—Shift+Tab; Right
arrow—Tab; Up arrow—Page Up; Down arrow—Page
Down
