32 Convertible Attachment slots for the posts on the FlexDock for the
keyboard and LE-Series, or the posts on the convertible keyboard (note
docking attach that the guide posts on the keyboard must be in the up or
points raised position for proper attachment).
There are two attachment points for mating the Tablet PC
to the Motion Convertible Keyboard. When the Tablet PC
is attached to the keyboard, the Tablet PC can be angled
to provide a comfortable viewing angle.
33 Docking port Connects the Tablet PC with the Motion FlexDock for the
LE-Series (not pictured in the illustration) and provides
the required signal connections when the Tablet PC is
docked. Refer to the Installation Guide provided with the
FlexDock for the LE-Series unit for more information.
34 Motion The Motion Accessory Port is for connecting input/output
Accessory devices directly to the Motion Tablet PC. For example,
Port this is the port for attaching the optional external DVD/
CD-RW Drive to the Tablet PC - all power to the drive is
provided through this port. Requires purchase of the
optional Motion Accessory Port Y-Cable.
35 External An external battery connector is included on the backside
battery of the LE-Series Tablet PC; the sliding panel must be
connector (not opened before attempting to attach the optional
shown) Extended Battery.
