ADTEK CS2-SG Manual page 11

■ Field Calibration
MEASURING
16*88
PAGE
Enter the password
Pcode
to access
enter
Programming Level
&
Enter the password
enter
to access Field
Fcode
Calibration Level
NO YES
Pass Code
Press
default=2000
Rev 1.1
2023-01-11
◎Once the user select field calibration, the [ lOsc ](step A-2) and [hIsc](A-3)
will be instead of [ caLls ] and [ caLhs ], and can not to be change. If user has to
change the scaling, it's the only way to access field calibration level to set in
[ caLls ](step F-2) and [ caLhs ](step F-4).
◎Please double check the [ lOsc ](step A-2) and [ hIsc ](A-3) are correct after
selection the def lt or f ield .
Adjust the structure to be a lower signal output status (or any lower status)
caLlo
and keep it in stable.
00000
caLlo : Field Calibration Low
» Press
to read signal of the lower status.
» Press
again to finish the calibration lower point, and go to next page.
caLls : the value to be set is relative to Field Calibration lower poin
caLls
00000 » Press
to set the value of lower scale.
Adjust the structure to be a higher signal output status (or any higher
caLhi
00000
status) and keep it in stable.
caLhi : Field Calibration High
» Press
to read signal of the higher status.
» Press
again to finish the calibration higher point, and go to next page.
caLhs : the value to be set is relative to Field Calibration higher point
caLhs
00000 » Press
so set the value of Higher scale
Csel : Calibration parameter selection
Csel
def lt » Press
to access the function and stand by selection
» Press
or to select
(default: def ld );
Settable: def ld / f ield
def ld (default calibration) f ield (Field calibration)
