② Mode key (MODE) :
Press the [MODE] button to enter the mode selection main
page → rotate [Knob 1] to select the mode → press [Knob
1] to enter the corresponding mode interface →Set the
parameter of the project by pressing or rotating [Knob 1]
→ press [BACK] Back to previous
CCT MODE : [Knob1] Adjust INT, [Knob2] Adjust CCT,
[Knob3] Adjust G/M
HSI MODE : [Knob 1] Adjust INT, [Knob 2] Adjust HUE,
[Knob 3] Adjust SAT
RGB MODE : [Knob 1] Adjust overall INT, Press [Knob 1]
Button, Switch to RGB adjustment, [Knob 1] Adjust the
brightness of the red light, [Knob2] Adjust the brightness
of the green light, [Knob 2] Adjust the brightness of blue
light.
GEL MODE (GEL) :
select GEL mode, select 3200K or 5600K color temperature
(CCT), and select the corresponding color paper of Rosco
or LEE brand to output the desired light.
Source MODE (Source) :
key to select Source mode, choose the desired light source
effect
EFFECT MODE (EFFECT) :
key to select FX mode, A variety of light effects are
available: Lightning, CCT Loop, candle, Bad bulb, TV,
Paparazzi, Explosion, Pulsing, Disco, Cop Car, Hue Loop.
Rotate and short press [Select ] key to
Rotate and short press [Select]
Rotate and short press [Select]
11
CCT HSI RGB
GEL Source Effect
CCT
INT
10.5%
CCT
6800K
G/M
0
HSI
INT
10.0%
HUE
0 °
SAT
100%
RGB
INT
11.2%
R G B
84 10 10
GEL
L002 Rose Pink INT
100.0%
L007 Pale Yellow
3200K 5600K
L019 Fire
R L
L021 Gold Amber
L025 Sunset Red
L026 Bright Red
Source
INT
10.0%
Tungsten
Effect
INT
18.1%
CCT
10000K
SPD
1
Lightning
