FUNCTION INTRODUCTION &
INSTRUCTION FOR USE
① Menu (MENU) :
Press the MENU button to enter the menu setting page → Rotate
[Knob①] select project → Press [Knob①] Enter the project settings
interface → Press or rotate [Knob①] set the parameters of the project →
Press [BACK] Return to the previous menu
DMX SETTINGS(Figure1) :
and [PROFILES MODE(8bit/16bit )]
DIM CURVE(Figure2) :
BT SETTINGS(Figure3) :
STUDIO Mode(Figure4) :
FREQUENCY SETTINGS(Figure5) :
FAN SETTINGS(Figure6) :
LANGUAGE(Figure7) :
SYSTEM SETTINGS(Figure8) :
Figure1
MENU
DMX SETTINGS
Figure3
MENU
BT SETTINGS
Figure5
MENU
FREQUENCY SETTINGS
Figure7
MENU
LANGUAGE
SETTINGS DMX parameter, [ADDRESS(001-512)]
Set DIM CURVE, [Linear, Log, Exp, S]
bluetooth switch, BT Reset
Setting up studio mode and non-studio mode
SETTINGS Dimming Frequency
Set the cooling fan mode
Set system language
View system information and Factory Reset
Figure2
DMX SETTINGS
PROFILES ADDRESS
8bit 1
16bit
Figure4
BT SETTINGS
Bluetooth
ON
BT Reset YES NO
Figure6
FREQUENCY SETTINGS
25000
Hz
Figure8
LANGUAGE
ENGLISH
简体中文
10
MENU
DIM CURVE
MENU
STUDIO
MENU
Smart
FAN SETTINGS
MENU
SYSTEM SETTINGS
FW Ver: V1.0
UID: GY150R-US
Factory Reset
SYSTEM SETTINGS
DIM CURVE
Linear Exp
Log S
STUDIO
ON
FAN SETTINGS
High Silent
YES NO
