4.3.7 Connecting the Cord of the Scaler Handpiece
connect the piezoelectric pilot wires of the cord to the m2 terminal in accordance with the
indicated polarity. Connect the LED wires (purple and grey of the handpiece cord) to connector
m3 in accordance with the indicated polarity.
CAUTION: Do not invert the position
on the connector ( Figure 4 a pagina 18
of the red wire and black wire of the scaler
handpiece cord.
Purple
Grey
M3
4.3.8 Standard Connections
to facilitate the
compact piezo LED in the different types of
dental units, there are 7 available "standard"
connection layouts, each equipped with a
connecting cable to the different dental unit.
CAUTION: if long connections are
required for the power supply, use wires with
a suitable wire gauge, for example 1.5 mm
18
) wires of the scaler handpiece cord together
with other cables.
M2
Red
Black
Figure 4 – Handpiece cord connection.
installation of NOTE*: Near the connection on the module
it is advisable to wind the power line 3 times
on a ferrite (see following chapters). The
ferrite is not supplied standard. Following is a
brief list of the usable models:
.
2
CAUTION: Do not wire the red and black
Scaler handpiece cord
• Philips CST17/9.5/13-3S4;
• Ferroxcube CST17/9.5/13-3S4;
• Wurth 74270091.
