18" LCD monitor
INSTALLING THE MONIT OR
The monitor is equipped with an auto sensing power supply for
voltage ranges from 110~240VAC, 60/50Hz. Confirm the line
voltage designation on the rear panel of the monitor.
FOLLOW THESE STEPS T O INSTALL THE
MONITOR
Before you connect the cables, make sure that the monitor
1.
and the computers are both turned off.
Plug one end of the 15-pin signal cable to the monitor and
2.
the other end to the video signal connector at the rear of the
system. Tighten the two screws on the cable connector on
both ends. Otherwise the screen will be abnormal and the
LED light will be yellow instead of the normal green color.
Connect the power to the monitor through the AC/DC
3.
adapter.
Connect the power cord to the AC outlet. See illustration
4.
below.
CHAPTER 2
9
