Image Adjust
Auto Tune
H./V. Position
H. Size
Phase
1 Exit
Auto Tune : automatically sizes, centers, and fine tunes the video signal to eliminate
waviness and distortion. Press the button
NOTE: Auto tune works with most common video cards. If using this function does
not work on your monitor, lower the video refresh rate to 60 Hz and try again (See
computer or graphic card user guide to adjust refresh rate.) The panel may be
manually tuned using the horizontal and vertical phase controls shown below.
H/V Position : Press button
Horizontal Position moves screen image left or right.
: moves screen to right, ▼ : moves screen to left.
Press the button
Vertical Position moves screen image up or down.
: moves screen to up, ▼ : moves screen to down.
H. Size : adjusts the width of screen image. ▼ decreases width of screen image,
increases width of screen image.
Phase : fine tunes the video distortion. Press ▼ or
to select H. or V. position.
to toggle between H. or V. Position.
2 Select
to obtain a sharper image.
to adjust to user preference.
6
