SGETF10xx-1xx
Cable Specifications
Fiber cable
- Continued
SGETF1029-112
SGETF1029-113
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
SGETF1029-116
SGETF1029-117
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
(Category 5 -- minimum requirement)
Copper cable
• Gauge = 24 to 22 AWG; Attenuation = 22.0 dB /100m @ 100 MHz
• Straight-through OR crossover cable may be used.
• Shielded twisted-pair (STP) OR unshielded twisted-pair (UTP) may be used
• All pin pairs (1&2, 3&6, 4&5, 7&8) are active in a gigabit network.
• Use only dedicated wire pairs for the active pins; e.g., blue/white & white/blue,
orange/white & white/orange, etc.
• Do not use flat or silver satin wire.
24-hour Technical Support: 1-800-260-1312 International: 00-1-952-941-7600
10
-- Continued
1310nm TX / 1550nm RX single mode
1550nm TX / 1310nm RX single mode
min: -3.0 dBm max: +2.0 dBm
min: -23.0 dBm max: -3.0 dBm
20.0 dB
1510nm TX / 1590nm RX single mode
1590nm TX / 1510nm RX single mode
min: -2.0 dBm max: +3.0 dBm
min: -26.0 dBm max: -3.0 dBm
24.0 dB

Technical Specifications

For Transition Networks' Model SGETF10xx-1xx or equivalent
Standards: IEEE 802.3ab™, IEEE 802.3 2000
Data Rate / Delay: 1000 Mbs/300 nsec
Dimensions: 3.25" x 0.1" x 4.8" (82mm x 25mm x 122mm)
Weight: 3 oz. (91 g) approximately
Power Supply 12VDC @ 0.8A (minimum)
Power Consumption: 5.4W, 450mA @ 12VDC
Packet Size: 10 Kbytes (maximum)
MTBF* 382,000 hours (MIL217F2 V5.0) (MIL-HDBK-217F)
1,345,000 hours (Bellcore7 V5.0)
Operating Temp: Tmra** 0°C to 50°C (32°F to 122°F)
Storage Temp: -15°C to 65°C (5°F to 149°F)
Humidity: 10% to 90%, non condensing
Altitude: 0 to 10,000 feet
Warranty: Lifetime
*MTBF is estimated using the predictability method. This method is based on MIL-217F at 25°C
ambient temperature, typical enclosure heat rise of 10°C, and nominal operating conditions and
parameters. Installation and configuration specific MTBF estimates are available upon request.
Contact Technical Support.
**Manufacturer's rated ambient temperature.
For the most up-to-date information on the SGETF10xx-1xx media converter, view the user's
guide on-line at: www.transition.com.
The fiber optic transmitters on this device meet Class I Laser safety requirements per IEC-
825/CDRH standards and comply with 21 CFR1040.10 and 21CFR1040.11.
WARNING: Visible and invisible laser radiation when open. Do not stare into the beam or view
the beam directly with optical instruments. Failure to observe this warning could result in an eye
injury or blindness.
WARNING: Use of controls, adjustments or the performance of procedures other than those
specified herein may result in hazardous radiation exposure.
IMPORTANT: Copper based media ports, e.g., Twisted Pair (TP) Ethernet, USB, RS232, RS422,
RS485, DS1, DS3, Video Coax, etc., are intended to be connected to intra-building (inside plant)
link segments that are not subject to lightening transients or power faults. Copper-based media
ports, e.g., Twisted Pair (TP) Ethernet, USB, RS232, RS422, RS485, DS1, DS3, Video Coax, etc.,
are NOT to be connected to inter-building (outside plant) link segments that are subject to
lightening transients or power faults.
