Configuring and Performing Appliance Data Backups
Mode 770 works only for MARS Appliances running the same software generation (4.x or 5.x). Use 775
Note
to support a mixed environment of 4.x to 5.3.x software and when performing migrations from 4.x to
5.3.x. Due to difference of UID/GID between the 4.x to 5.x releases, you must allow r-x so an appliance
running 5.3.x can import from files exported by a 4.x appliance.
In the /etc/exports file, add the following line:
Step 3
Restart the NFS service.
Step 4
Configure the NetApp NFS Server
The NetApp NFS server differs from other Linux/UNIX NFS servers in that NetApp restricts the
functionaliy of the shell environment running on the server. As such, you must use an external
UNIX/Linux admininstrative host to change the permissions and ownership of the exported NFS
directory.
Before You Begin
•
To prepare the NetApp NFS server so that the MARS Appliance can archive to it, follow these step:
If you have not exported an directory on the NetApp NFS appliance, and perform the following task from
Step 1
the NetApp's web GUI.
a.
a.
b.
c.
Note
d.
Install and Setup Guide for Cisco Security MARS
6-28
/archive/nameOfYourMARSBoxHere MARS_IP_Address(rw)
/etc/init.d/nfs restart
To perform the tasks in this procedure, you must configure an external Linux/UNIX admininstrative
host. For information on configuring such a host, refer to the documentation for you Network
Appliance server.
Connect to the NetApp administrative host (http://hostname/na_admin/).
Click FilerView, then click NFS on the menu in the left pane.
If the exported directory already exists, click Manage Exports under NFS. Otherwise, click Add
Export under NFS.
Select the following options on the NFS Export Wizard page, and click Next:
Read-Write Access
–
Root-Access
–
Security
–
The NFS Export Wizard - Path page appears.
If you are using a temporary NetApp administrative host, you can disable the host's access to the
exported directory. To do so, do not select the Root-Access option. This configuration disable
access by the host to the exported NFS directory.
Enter the path to the desired export directory in the Export Path field, and click Next.
Chapter 6
Administering the MARS Appliance
OL-14672-01
