Insert two M4x6 mm Screws through the Screw Holes on
3.
the Wall-Plate Clamp and into the Screw Holes on the Wall
Plates.
Using the Phillips Head Screwdriver tighten the M4x6 mm
4.
Screws.
Repeat steps 2 - 4 to install the remaining five Wall-Plate
5.
Clamps.
If the combined width of the Displays is greater than 1 m (39.37
") you must use the Small Wall Plate when connecting the Wall
Plates together.
On a flat surface, align the four Wall Plates and the Small
6.
Wall Plate side by side so that the wall plates are touching,
with the Small Wall Plate in the middle.
Repeat Steps 2 - 4 to install the remaining seven Wall-Plate
7.
Clamps.
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Wall Plates with Small Wall Plate in the Middle
