Flat-Screen TV Wall Mount -
Articulating - Heavy Duty
FPWARTB2
FR: Guide de l'utilisateur - fr.startech.com
DE: Bedienungsanleitung - de.startech.com
ES: Guía del usuario - es.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
IT: Guida per l'uso - it.startech.com
JP: 取扱説明書 - jp.startech.com
For the latest information, technical specifications, and support for
this product, please visit www.StarTech.com/FPWARTB2.
Manual Revision: 12/04/2018
*actual product may vary from photos
Advertisement
Table of Contents
Related Manuals for StarTech.com FPWARTB2
Summary of Contents for StarTech.com FPWARTB2
- Page 1 Flat-Screen TV Wall Mount - Articulating - Heavy Duty FPWARTB2 *actual product may vary from photos FR: Guide de l’utilisateur - fr.startech.com DE: Bedienungsanleitung - de.startech.com ES: Guía del usuario - es.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com IT: Guida per l’uso - it.startech.com...
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
- Page 3 Warning statements Mensagens de aviso Make sure to assemble this product according to the instructions. Failure to do so might result in personal Certifique-se de que monta este produto de acordo com as instruções. O incumprimento pode resultar injury or property damage. em ferimentos pessoais ou danos de propriedade.
-
Page 4: Table Of Contents
Technical specifications .......................... 2 Package contents ............................3 Requirements ............................. 6 Installation ....................7 Prepare FPWARTB2 for mounting ....................... 7 Attach the wall mount to the wall ...................... 8 Reattach the decorative covers ......................9 Assemble the TV mount ......................... 10 Mount a TV with a flush mounting surface .................. -
Page 5: Introduction
Introduction Product dimensions +5° -8° +5° -5° Instruction manual... -
Page 6: Technical Specifications
Technical specifications Unless otherwise indicated, the technical specifications in the table below apply to the TV or display. Type of measurement Measurement VESA mounting hole pattern 200x200 on the TV mount 300x200 300x300 400x200 400x300 400x400 600x400 Weight capacity of TV mount 45 kg (99 lb.) Tilt +50 to -80... -
Page 7: Package Contents
Package contents Wall mount Horizontal brackets Qty: One Qty: Two Vertical brackets Wrench Qty: Two Qty: One Bracket screws Nuts Qty: Four Qty: Four Instruction manual... - Page 8 Mounting screws M5x14 mm screws Qty: Two Qty: Four M6x14 mm screws M6x30 mm screws Qty: Four Qty: Four M8x30 mm screws M8x50 mm screws Qty: Four Qty: Four Instruction manual...
- Page 9 Small washers Large washers Qty: Four Qty: Four Small spacers Large spacers Qty: Eight Qty: Eight Screws Concrete anchors Qty: Six Qty: Six Instruction manual...
-
Page 10: Requirements
Qty: Six Qty: One Requirements • A display or TV that is compatible with one of the VESA mounting hole patterns FPWARTB2 supports • A Phillips screwdriver Requirements are subject to change. For the latest requirements, please visit www.StarTech.com/FPWARTB2. Instruction manual... -
Page 11: Installation
Installation Prepare FPWARTB2 for mounting 1. Remove the decorative covers from the wall mount. 2. Use the wrench provided to remove the two bolts from the back of the mount attachment and slide the TV mount up and away from the wall mount. (figure 1) -
Page 12: Attach The Wall Mount To The Wall
Attach the wall mount to the wall Warning! The wall mount is designed to be installed on a wood stud, solid concrete, or cinder block wall. The wall structure should be capable of supporting at least four times the weight of the mounted equipment. The mounting hardware included with this product may not be adequate for installation on certain wall structures. -
Page 13: Reattach The Decorative Covers
Reattach the decorative covers • When the wall mount is attached to the wall, snap the decorative covers back onto the wall mount. (figure 3) figure 3 Wall mount Decorative cover Instruction manual... -
Page 14: Assemble The Tv Mount
Assemble the TV mount 1. Slide the two horizontal brackets through the top and bottom channels of the TV mount. 2. Insert a mounting screw in the top and bottom holes in the TV mount, and use a Phillips screwdriver to tighten the screws. (figure 4) figure 4 Mounting screw Horizontal brackets... - Page 15 3. Select the placement of the vertical brackets that works best with the VESA mounting hole pattern on your TV. (figure 5) figure 5 Vertical bracket Vertical bracket Instruction manual...
- Page 16 4. Insert the bracket screws through the vertical brackets and the horizontal brackets. 5. Use the provided wrench to tighten the nuts onto the bracket screws. (figure 6) figure 6 Vertical bracket Bracket screw Wrench Horizontal bracket Instruction manual...
-
Page 17: Mount A Tv With A Flush Mounting Surface
Mount a TV with a flush mounting surface To accommodate different TV designs, the FPWARTB2 comes with five sets of screws of different lengths and diameters, two sizes of washers, and two sizes of spacers. 1. To select the combination of mounting hardware that you need to use to attach the vertical brackets to the TV, complete the following: •... -
Page 18: Mount A Tv With A Recessed Mounting Surface
Mount a TV with a recessed mounting surface To accommodate different TV designs, the FPWARTB2 comes with five sets of screws of different lengths and diameters, two sizes of washers, and two sizes of spacers. 1. To select the combination of mounting hardware that you need to use to attach the vertical brackets to the TV, complete the following: •... - Page 19 2. Line up the vertical brackets with the mounting holes on the back of the TV. 3. Place the large washers over the vertical brackets. 4. Insert the M6x30 mm screws, M8x30 mm screws, or M8x50 screws through the washers, vertical brackets, spacers, and into the back of the TV. 5.
-
Page 20: Attach The Tv To The Wall Mount
Attach the TV to the wall mount Warning! Make sure that the weight of the TV doesn’t exceed the weight capacity of this product. If you exceed the weight capacity, you might experience personal injury or damage to the product. This product can support the following weight: Up to 45 kg (99 lb.) Warning! Attaching the TV is a two-person job. -
Page 21: Route The Cables
Route the cables 1. Remove the decorative covers from the arms of the wall mount. 2. Position the cables in the decorative covers and reattach them to the arms of the wall mount. (figure 10) figure 10 Instruction manual... -
Page 22: Adjust The Tilt And Swivel Angle Of The Tv
Adjust the tilt and swivel angle of the TV 1. Use the provided wrench to loosen the bolts in the side of the TV mount. 2. Position the TV at the angle that you want. 3. Use the provided wrench to tighten the bolts in the side of the TV mount. (figure 11) figure 11 Wrench Instruction manual... -
Page 23: Technical Support
Limitation of liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 24 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
